Section 4
Connecting a sensor to
the Model 511
Model 511 User's Manual

Serial Communication Option

Model 511 monitors (Cat. No. 6416-00) are available with a serial communications option
which allows patient trend information to be downloaded into the Novametrix NovaCARD
Data Archive System or other communicating devices. A 15-pin mini-D connector
(
PATIENT/SERIAL INTERFACE
cable (Novametrix Cat. No. 6493-01) is required for connection between the monitor and
the communicating device.
The
PATIENT/SERIAL INTERFACE
communication. When attaching a sensor for patient monitoring, the 6292-01 cable must
be connected to the
the cable. When utilizing the monitor for serial communication the 6293-01 interface cable
must be used, this cable terminates in a 9 pin D female for connection to the communication
device.

Connecting a sensor to the Model 511

1. Plug the 6292-01 cable into the PATIENT/SERIAL INTERFACE connector.
Model 511
OxySnap connection for
SuperBright™ sensor
2. Connect an OxySnap Finger or "Y" sensor into the end of the cable.
3. Apply the sensor as described in "Y-Sensor" on page 15.
) on the top panel indicates the option is installed. An interface
connector is shared between patient monitoring and serial
PATIENT/SERIAL INTERFACE
6292-01 cable
01-May-96
, the sensor will plug into the other end of
23
