HD-SDI NTSC to PAL CONVERTER
Powering up your converter - inputs status:
1.
Power up the unit with the supplied
power adapter
2.
Screen will power up with the
Status
Power supply adapter dimensions:
With power plug, dimensions are:
S
is the
SDI
input, when it has a
a.
signal it will display the Camera's
HD-SDI signal which will be
1080i 59.94
H
is the
HDMI input
and can be
b.
used with other converters that
transmit the signal over HDMI.
When it has signal it will display
the HD signal from the camera
D
is the current
Scaling output
c.
format. The format that will come
out of the converter
Dimensions:
79.5mm x 123mm x 29.5mm
39.45 x 70.36 x 32.78 mm
39.45 x 70.36 x 58 mm
Selecting your output scaling factor:
1.
To set the
Scaling
Input
right arrows to scroll through the menu
until you get Scaling.
button.
2.
In the
Scaling
arrow keys to scroll through the scaling
menu until you get to
Press the
output options.
3.
Use the left and right arrow keys to scroll
through the different output formats
a.
If you are using this camera in a
PAL
the converter output format to
1080i 50
b.
If you are using
cable in to
c.
If you are using
HDMI cable into the
output, use the left and
Press the
Enter
menu, use the left and right
Output
Format.
Enter
button to highlight the
region, we recommend setting
SDI
in, plug a coax
3G/HD/SD SDI Output 1
HDMI
in, plug a
HDMI output
