1CAM MK5 SPECIFICATIONS

All Models

Sensor: Back-illuminated CMOS
Control: RS232, RS485 and Ethernet
Max Video Record: 1080/60p
Live HD Resolution: 1080/60
Max Still Resolution: 6544 x 3680 [24.3MP]
Depth Rating: 6500m (*bulkhead)
Memory: 608GB (512GB Primary with 96 Backup)
Framerates: 24p/60i/60p
Zoom: 10x Optical
Sensitivity: 1 Lux [Low Lux]
View Angle In Water: 60° (flat port)
Viewport: Scratch resistant sapphire
Focusing System: Manual, Auto
Voltage Range: 15 - 32Vdc (48-72Vdc version available)
Lens:
Carl Zeiss Vario-Sonnar T
●
10 × (Optical)*
●
Filter diameter: 52mm
●
F1.8 ~ F3.4
●
Focal length: * f= 3.8 mm ~ 38.0 mm
●
* When converted to a 35 mm still camera
1
For movies : 26.0 mm ~ 260 mm (16:9)
●
For photos: 26.0 mm ~ 260 mm (16:9)
●
*when [SteadyShot] is set to [Off]
Video recording bitrates and storage:
The following list shows the bitrate, pixels and aspect ratio of each recording mode
for movies (movie + audio, etc).
High-definition image quality (HD):
PS: Max. 28 Mbps 1920 x 1080 60p pixels/16:9
FX: Max. 24 Mbps 1920 x 1080 pixels/16:9
FH: Approx. 17 Mbps (average) 1920 x 1080 pixels/16:9
HQ: Approx. 9 Mbps (average) 1440 x 1080 pixels/16:9
LP: Approx. 5 Mbps (average) 1440 x 1080 pixels/16:9
Standard-definition image quality (SD):
HQ: Approx. 9 Mbps (average) 720 x 480 pixels/16:9, 4:3
The photo file format is compatible with DCF Ver.2.0, Exif Ver.2.3 and MPF Baseline.
Image Storage @ 24.1MP:
352GB: 35,000 images
608GB: 60,000 images
Compression:
The video is compressed with MPEG-4 AVC/H.264
There is also embedded audio: Dolby Digital 2ch/5.1ch Dolby Digital
