KNX Module SAS-04.16 Quick Manual

SWITCH ACTUATOR
SAS-04.16
BASIC INFORMATION
The switch actuator receives KNX telegrams and switches up to 4 independent loads. Each output has a bistable
relay, which can be manually controlled.
• 4 independent channels for a maximum capacitive load of
• Ability to connect outputs to different phases
• Manual control of outputs using front panel buttons
• LED indication of output status
• Extendet logic and scenario functions for each output
• Ability to select output mode (NO or NC)
• Saving settings during a KNX power failure
• Power supply via KNX bus
• DIN rail 35mm mounting
1. Outputs 2. Output status indicator LED
4. Programming button
module-electronic.ru, info@module-electronic.ru
phone: +7-495-150-27-25
page 1
140µF
1
6
3. Output control button
5. Programming LED
Module Electronic LLC
МГРЛ-27.12.1931-001.04 ПС
2
3
4
5
6. KNX connector
PASSPORT
