System board and components
LAN 2 /
LAN 1 USB 3.0
Buzzer
Figure 265: Slots and bolts for M.2 SSDs
1 M.2 slot 1
15.6.2

Installing an M.2 SSD

Upgrade and Repair Unit
(URU)
Tools: – Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver
Preliminary steps
▶
"Shutting down the server" on page
▶
"Disconnecting the power cord" on page
▶
"Getting access to the component" on page
▶
"Removing the air duct" on page
▶
"Removing the crossbar" on page
▶ If applicable,
"Removing the expansion card" on page
406
Slot 4 (CPU 1) - slot riser card
SERIAL
Slot 3 (CPU 1)
Slot 2 (CPU 1)
Slot 1 (CPU 1)
JP2
JP1
58.
62.
Upgrade and Maintenance Manual
TPM
2 M.2 slot 2
Hardware: 5 minutes
Software: 15 minutes
45.
46.
47.
SATA
4-7
SATA
0-3
JP3
237.
RX2520 M5
