  • Page 1 User Manual IDK-2119 Series 19" High Brightness SXGA LED-Backlight Display 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...
  • Page 2 The documentation and software included with this product are copyrighted 2014 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 Our dealers are well trained and ready to provide the support you need to get the most from your Advantech products. In fact, most of the problems reported are minor and easily resolved over the telephone.
  • Page 4 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, customers are billed according to the cost of the replacement materials, service time and freight.

  • Page 5: Table Of Contents

    Contents Chapter Overview..........1 General Description .................. 2 Specifications .................... 2 1.2.1 LCD Panel..................2 1.2.2 LED Driver Board................2 1.2.3 Touchscreen (R series)..............2 1.2.4 Environment.................. 2 Mechanical Characteristics ............... 3 1.3.1 IDK-2119N-K2SXA2E ..............3 1.3.2 IDK-2119R-K2SXA2E ..............5 Functional Block Diagram ................. 7 Figure 1.1 Functional block diagram..........
  • Page 6 Chapter Touchscreen and Controller .... 23 Touchscreen (Optional: for IDK-2119R only).......... 24 5.1.1 Touch Characteristics ..............24 5.1.2 Optical Characteristics..............24 5.1.3 Environmental Characteristics ............ 24 5.1.4 Mechanical Characteristics............24 5.1.5 Electronic Characteristics ............24 5.1.6 General Specifications..............25 Touch Controller (Optional: for IDK-2119R only) ........25 5.2.1 Touch Controller Characteristics ..........

  • Page 7: Chapter 1 Overview

    Chapter Overview 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 8: General Description

    LCD display and LED driver board. This series is also available with various touch- screen options and enhancements, such as AR surface treatment and optical bond- ing solutions. The IDK-2119 series supports a high brightness of 1200 cd/m2 at the maximum power consumption of 29.61 W. Featuring a high level of brightness and wide operating temperature range, IDK-2119 provides superior sunlight readability and is ideal for both semi-outdoor and outdoor environments.

  • Page 9: Mechanical Characteristics

    Mechanical Characteristics 1.3.1 IDK-2119N-K2SXA2E Front View IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...
  • Page 10 Rear View IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 11: Idk-2119R-K2Sxa2E

    1.3.2 IDK-2119R-K2SXA2E Front View IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...
  • Page 12 Rear View IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 13: Functional Block Diagram

    Below is a functional block diagram of the 19-inch color TFT-LCD module. Figure 1.1 Functional block diagram Touchscreen Driver Please download the touchscreen driver from www.advantech.com Absolute Maximum Ratings The absolute maximum allowable ratings for this module are as follows: 1.6.1...

  • Page 14: Absolute Environmental Ratings

    1.6.3 Absolute Environmental Ratings Item Symbol Min. Max. Unit Conditions Operating Temperature [oC] Operating Humidity [%RH] Storage Temperature [oC] Storage Humidity [%RH] Note 1: Ta must not exceed 25 °C Note 2: Permanent damage to the device may occur if the maximum values are exceeded.

  • Page 15: Chapter 2 Electrical Characteristics

    Chapter Electrical Characteristics 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 16: Power Specifications

    Power Specifications The input power specifications are as follows: Table 2.1: Power Specifications Symbol Parameter Min. Typ. Max. Unit Condition  Logic/LCD Drive [Volt] Voltage 0.94 Vin = 5.0 V; all white Input Current pattern; at 60 Hz [Watt] Vin = 5.0 V; all white VCC Power pattern;...
  • Page 17 Note 1: The LED lifetime is defined as the time before the module brightness decreases to 50% of the original brightness when at an ambient temperature of 25 °C, with a typical LED current of 800 mA. Note 2: The LED driving condition is defined for each LED module (6 LED serial). Note 3: The variance in power consumed by the LED light bar is 10%.
  • Page 18 IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 19: Chapter 3 Signal Characteristics

    Chapter Signal Characteristics 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 20: Pixel Format Image

    Pixel Format Image The following figure shows the relationship between input signals and the LCD pixel format. Pin Description The module uses a pair of LVDS-compatible SN75LVDS82 receivers (Texas Instru- ments). LVDS is a differential signaling technology developed for LCD interfaces and high-speed data transfer devices.
  • Page 21 Table 3.1: Pin Description RxEIN1- Negative LVDS differential data input (even data) RxEIN1+ Positive LVDS differential data input (even data) Power ground RxEIN2- Negative LVDS differential data input (even data) RxEIN2+ Positive LVDS differential data input (even data) RxECLKIN- Negative LVDS differential clock input (even clock) RxECLKIN+ Positive LVDS differential clock input (even clock) RxEIN3-...

  • Page 22: Input Data Format

    Input Data Format Note 1: Typically, DE mode only. VS and HS on the EVEN channel are not used. Note 2: Please follow VESA. Note 3: 8-bit input Interface Timing 3.4.1 Timing Characteristics Table 3.2: Timing Characteristics Signal Item Symbol Min.

  • Page 23: Input Timing Diagram

    3.4.2 Input Timing Diagram Power ON/OFF Sequence The VDD power and lamp ON/OFF sequence, in addition to the interface signals, are shown below. Signals from any system should be in Hi-Z state or at a low level when the VDD is off. IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822...
  • Page 24 Power Sequence Timing Parameter Value Unit Min. Typ. Max. [ms] [ms] [ms] [ms] [ms] [ms] [ms] [ms] [ms] [ms] 1000 [ms] IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 25: Chapter 4 Connector And Pin Assignment

    Chapter Connector and Pin Assignment 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 26: Tft Lcd Module

    TFT LCD Module The physical interface of the connectors on the TFT LCD module are described in this section. The components and signals accommodated by these connectors are as follows: 4.1.1 Connectors Table 4.1: Connectors Connector Name / Description Interface Connector / Interface Card Manufacturer JAE / P-TWO Type / Part Number...

  • Page 27: Led Light Bar Connector Signals

    4.2.1 LED Light Bar Connector Signals Connector No. Pin No. Input Color Function Upper HI 1 Power supply for backlight unit GND 1 Black Ground for backlight unit Lower HI 2 Power supply for backlight unit GND 2 Black Ground for backlight unit Cable Length: 250 mm+ / -10 mm 4.2.2 LED Driver Board...
  • Page 28 4.2.2.2 Input Connector Pin Definition Table 4.4: Input Connector Pin Definition (CN4) Pin No. Pin Definition Vin (+12 V) Vin (+12 V) ON/OFF (0V: Off; +5 V: On) Dimming (PWM) 4.2.2.3 Output Connector Pin Definition Table 4.5: Output Connector Pin Definition (CN1 and CN2) Pin No.

  • Page 29: Touchscreen And Controller

    Chapter Touchscreen and Controller 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 30: Touchscreen (Optional: For Idk-2119R Only)

    Touchscreen (Optional: for IDK-2119R only) 5.1.1 Touch Characteristics The touch panel features a resistive-type touchscreen for use with flat LCD displays. When touched, using either a round-ended resin pen or finger, the touch panel circuit identifies the touch coordinates based on the voltage at the point of contact on the screen.

  • Page 31: General Specifications

    Tail Length Touch Controller (Optional: for IDK-2119R only) The Advantech ETM-RES04C Touch Control Board is the ultimate combo board. This touch panel controller enables the optimum performance of analog-resistive touch panels for 5-wire models. The controller communicates with the PC system directly through USB and RS-232 connector.

  • Page 32: Pin Assignment And Description

    Serial Interface  EIA 232E (Serial RS-232)  No parity, 8 data bits, 1 stop bit, 9600 baud (N, 8, 1, 9600)  Supports Windows 2000 / Vista / XP/ 7, Windows CE 5.0 / 6.0 / 7.0, Windows NT4, Linux, DOS and QNX USB Interface ...
  • Page 33 5.2.2.2 JP1 Combo Interface Connector Pins and Signal Descriptions The combo interface connector, USB and RS-232, is a box, 2.0 mm, 10-pin, 90°, male-type lock connector developed for use with single-wire pins in a 5+5 pin header. The pins are numbered as shown in the following table. Signal Signal Function RS-232...

  • Page 34: Physical Dimensions

    5.2.3 Physical Dimensions ETM-RES04C-EEH4EE Touch Control Board (unit: mm) IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 35: Appendix A Optical Characteristics

    Appendix Optical Characteristics 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 36: Optical Characteristics

    Optical Characteristics The following optical characteristics are as measured when in stable condition at a room temperature of 25 °C. Table A.1: Optical Characteristics Item Unit Conditions Min. Typ. Max. Note Horizontal (right) CR = 10 (left) Viewing Angle [degree] Vertical (up) CR = 10 (down) Luminance Uniformity...
  • Page 37 Note 3: The luminance uniformity of the nine points can be determined by dividing the maximum luminance values by the minimum test point luminance Minimum Brightness of nine points Maximum Brightness of nine points Note 4: Regarding the measurement method, the LCD module should be stabilized at a set temperature for 30 minutes to avoid abrupt changes in temperature when measuring.
  • Page 38 IDK-2119 User Manual 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 39: Appendix B Handling Precautions

    Appendix Handling Precautions 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...

  • Page 40: Handling Precautions

    Handling Precautions Because the front polarizer is vulnerable to damage, we recommend taking additional care not to scratch the polarizer surface. Be sure to turn off the power supply when connecting/disconnecting from the input connector. In the event of exposure to water or other liquids, immediately wipe off all liquid droplets.
  • Page 41 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014 北京昌平阳坊镇极东未来产业园双创社区3层391 010 82795822 www.gcreat.cn...
