Installation manual octo
plus
Screw in adjustable feet
Insert disk-shaped insulation
under the tank.
Screw in 4 pcs adjustable feet
(SW24) and adjust tank level.
, Installing the burner
Position fire clay brick
back of the burner unit 2.
Mount burner unit and flange gas-
ket
3
onto the tank using 4 x hex
nuts DIN934-VZ/M12 and wash-
ers DIN125A-12-VZ 4.
Use fire clay bricks
5
attention to different shapes)
Installing the burner cover
Bend the tabs
1
in a vertical posi-
tion on both sides of the burner
unit.
Mount left and right covers 2, in-
cluding insulation.
Attach top cover
3
and secure
with 4 x sheet metal screws
M4x10
4
to the side panels.
Installation
1
2
1
into the
and
6
(pay
11
