- Page 1 Pellet boiler pellet elegance Operation manual for the system operator Read carefully before operating. DR-0030-EN / v28-202109...
-
Page 2: Table Of Contents
Content 1 About this manual 11 Temperature difference, charge control 2 Safety information 12 mySOLARFOCUS app 12.1 Requirements for use 3 Warranty, guarantee, liability 12.2 Connecting the control to the internet 3.1 Technical requirements for warranty and 12.3 Registering on the web server guarantee claims 12.4 Install app, register user 3.2 Conditions for claims... -
Page 3: About This Manual
– System may only be installed and put into ope- mation in this manual. ration by certified qualified personnel Software version for control (SOLARFOCUS service technician or SOLARFOCUS service partner. The manual describes the software version 19.040 manager-touch of the eco control;... -
Page 4: Warranty, Guarantee, Liability
– We are not liable for parts that were not produced by SOLARFOCUS. However, we are prepared to transfer our existing claims against the producer (relating to this defect) to the buyer. Operation manual pelletelegance... -
Page 5: Claims Rendered Void
– Only use fuel as specified in the next chapter – The repair and/or warranty replacement shall be Fuel. carried out on site or in the SOLARFOCUS fac- tory at our discretion. 4.2 Fuel – The company SOLARFOCUSwill determine whe-... -
Page 6: Accessories
3 Warranty, guarantee, liability 4.5 Accessories 4.6 Type plate Lifting aid – Optional accessories for carrying/moving the boi- ler. – Item 6144 4.7 CE declaration of conformity Abb. 2-1: Lifting aid mounted The conformity of the product is declared by the manufacturer in accordance with the Machinery Direc- Extension pack for operation as a room-sealed tive 2006/42/EC;... - Page 7 3 Warranty, guarantee, liability Overtemperature reset (OTR) – Functioning: At a boiler temperature > 95°C, the valve opens and directs cold water through the safety heat exchanger (which is placed in the water jacket of the boiler). This lowers the boiler temperature.
-
Page 8: Efficient And Low-Emission Operation
3 Warranty, guarantee, liability Emergency OFF switch 4.10 Functional components – The emergency OFF switch is a manually ope- rated safety device. The burner and the fuel sup- ply to the boiler are stopped. Circulation pumps remain in operation to dissipate heat and cool the boiler. -
Page 9: Combustion Principle
3 Warranty, guarantee, liability 4.11 Combustion principle Fuel path The pellets are sucked by the suction turbine into the intermediate pellet store 2. The pellet auger rotary valve transport the pellets to the filling cham- ber, where they fall onto the stainless steel com- bustion grate 6. -
Page 10: Technical Specifications
3 Warranty, guarantee, liability 4.12 Technical specifications elegance pellet Power range 2.9 - 9.9 4.4 - 14.9 5.9 - 19.8 7.2 - 24 [kW] Energy efficiency class Boiler class (acc. to EN 305:5 2012) Boiler efficiency - full load 93.80 93.90 94.40 Boiler efficiency - partial load 92.42... - Page 11 3 Warranty, guarantee, liability elegance pellet Regulation (EU) 2015/1187 Nominal heating output 14.9 15.5 [kW] Heating boiler energy efficiency class Energy efficiency class EEI of boiler and con- trol combined Energy efficiency index EEI of the heating boiler Energy efficiency index EEI of the boiler and control combined Space heating annual usage etaS Annual emission values...
-
Page 12: Dimensions And Connections
3 Warranty, guarantee, liability 4.13 Dimensions and connections Flue gas pipe connection aligned backwards Flue gas pipe connection aligned upwards 1 Buffer tank return / DHW tank return 2 Buffer tank flow / DHW tank flow â Pellet suction 3 Heating circuit 1 return 4 Heating circuit 1 flow 5 Heating circuit 2 return 6 Heating circuit 2 flow... -
Page 13: Use And Operation
5 Use and operation 5 Use and operation STOP The burner is switched off. No connected devices Touch display for operation heating requests are fulfilled. If the boiler is supplied with a mains power supply, the manager-touch boiler control starts. The control is ATTENTION - The burner must not start! Only started up to show the main screen. -
Page 14: Output Test Heating Circuit
5 Use and operation 5.3.1 Output test heating circuit 5.4 Customer menu The available electrical outputs can be switched on/off directly using the button. Can be used to test the function of individual components. ATTENTION - Only to be undertaken by qua- lified personnel. -
Page 15: Vacuum Output
An even reduction of the fill external boiler may only start when it receives the level in the pellet storage area is achieved. release from the SOLARFOCUS boiler (e.g. on the Selectively: The heads are successively sucked basis of a lack of fuel, operating fault). -
Page 16: Message Log
Password reset The current password is reset to the value solarfocus. Adopt as new password Enter a new password in the input field and press the button. -
Page 17: Qualified Personnel Menu
– The password predefined by the manufacturer support activities). is solarfocus The following points are helpful for setting up a PC/- – After login, the screen view of the control can router to control the VNC server, which requires know- be seen. -
Page 18: Abb
► The new password must be used to log on after restarting the VNC Viewer on the local PC. ► Press the Reset password button to reset the password to the default password solarfocus. Version 2: VNC viewer for access from an exter- nal PC (PC outside the home network) –... -
Page 19: Language Selection
5 Use and operation Write e-mail 5.4.6.4 mySOLARFOCUS app Used to manually send emails. The recipient’s address can be selected from the address book using To and CC or manually entered in the recipient line. Pressing the button displays the screen with infor- mation relating to online registration for the mySOLARFOCUS app (serial number, PIN, status, etc.) -
Page 20: Heating Circuit
6 Heating circuit 6.1 Heating circuit settings 6 Heating circuit Abb. 2-27 1 Heating circuit operating mode > 20 Abb. 2-26 2 Room settings (Button is only visible when the Room influence parameter 1 Outside temperature is set to On or Sliding; this can be found in the Qualified 2 Average outside temperature personnel system parameters) 3 Room temperature... -
Page 21: General Settings
6 Heating circuit Buffer difference Time switching The burner starts when the tank temperature top falls below the required flow temperature minus the buffer In this operating mode, the timed switch-over bet- difference. ween Heating mode and Reduced mode is defined. You can enter the times for heating mode Daily or In Example: blocks. - Page 22 6 Heating circuit 2-point heating curve Example for calculation of required flow tem- perature (see the following illustration): Flow temperature at outside temperature of -15°C = 45°C Flow temperature at outside temperature of +15°C = 22°C Current outside temperature = -5°C In the heating circuit operating mode Heating mode, the following applies: >...
-
Page 23: Dhw Heating
7 DHW heating Perceived Current 7 DHW heating Recommended adjust- outside tem- room tem- ment of heating curve perature perature Increase temperature too cold value at -5°C to +5°C Reduce temperature too hot DHW can be heated up in two ways: value at –... -
Page 24: Dhw Tank Settings
6 Heating circuit 7.1.1 DHW tank settings DHW tank operating mode Always off: The DHW tank charge pump is switched off permanently. Exception for frost protection mode: The DHW tank charging pump is activated if - the outside temperature is <2°C, and - the DHW tank temperature falls to <10°C. -
Page 25: Recirculation Control
8 Recirculation control Fresh water module settings 8 Recirculation control Pump control (optional additional function) Always off: The fresh water module pump is per- A recirculation line means that domestic hot water manently switched off; no domestic hot water is hea- can be quickly available at the extraction points (also ted up. -
Page 26: Recirculation Control - Options
6 Heating circuit Release mode Temperature- and time-controlled recir- culation Always off: The recirculation control is switched off permanently. Temperature-controlled recirculation is only available if a temperature sensor is connected for the recircu- Always on: The recirculation control is switched on lation temperature. -
Page 27: Buffer Tank
9 Buffer tank 9 Buffer tank 10 Solar system (optional additional function) The solar yield is charged into a solar tank. This tank can be a buffer tank or a DHW tank. Abb. 2-36 1 Buffer cylinder temperature top Abb. 2-37 2 Temperature of the energy source 3 Buffer cylinder temperature bottom 1 Collector temperature (measured at the col-... -
Page 28: Temperature Difference, Charge Control
11 Temperature difference, charge control 11 Temperature difference, 12 mySOLARFOCUS app charge control Function: The mySOLARFOCUS app allows you to (optional additional function) manager- use your smartphone to access specific eco touch control functions: – Set the room temperature and heating circuit flow temperature, including heating times. -
Page 29: Registering On The Web Server
(=DHCP OFF), i.e. the control has a constant IP address. 12.3 Registering on the web server The touch display must be registered on the SOLARFOCUS Web server: ► Press the app button Abb. 2-43 12.4 Install app, register user The mySOLARFOCUS app is available in the Apple Store and Google Play Store. -
Page 30: Add System
11 Temperature difference, charge control ► Press the Register new user button. As an alternative to the app, you can also add systems on the website: https://www.mysolarfocus.com Important: In principle only one user may access a system. If additional users are to access a system, then they must be approved in advance Approve additional users >... -
Page 31: Weatherman Function
> 28). Has your heating system been correctly regis- tered on the SOLARFOCUS web server? Is the connection status between the control and the SOLARFOCUS web server online? Abb. 2-47 Is the Send data parameter set to Yes? 13.1 Information... -
Page 32: Heating Circuit
13 Weatherman function The following applies for three menus: The level of Solar yield in the room influence can be set using the plus/minus buttons on Activate this function only if solar radiation directly the bar, in 10% steps, influences the heating circuit (e.g. solar radiation through a glass panel). -
Page 33: Buffer Tank Charging
14 Maintenance (and cleaning) Activate the weather influence domestic hot water The bar can be used to set the level of influence for function only if the DHW tank/domestic hot water each buffer tank individually. area is heated by a solar power system, or is charged 0% = if the burner has started and the buffer tank is from a buffer tank that is heated by a solar power sys- within a release time, then the buffer tank is com-... -
Page 34: Required Activities - Overview
13 Weatherman function Deashing in the boiler 14.1.1 Empty ash container Empty the ash container when the notification mes- sage on the boiler control display appears. In the course of emptying the ash container, a boiler clea- ning > 35 can also be performed. -
Page 35: Boiler Cleaning - Manual Activities
13 Weatherman function ► Open the 2 turnbuckles and remove the lid 14.1.2 Boiler cleaning - manual activities upwards. Two ways to start with the boiler cleaning: The burner is active ► Switch the boiler off (press the STOP button >... -
Page 36: Replace Stainless Steel Combustion Grate
13 Weatherman function 14.1.2.2 Check the stainless steel combustion 14.1.3 Replace stainless steel combustion grate support grate The stainless steel combustion grate must lie completely flat and horizontally. ► Switch the boiler to STOP > 13 and leave to cool. When inclined, ignition problems are possible, ►... -
Page 37: Check System Pressure
13 Weatherman function 14.1.4 Check system pressure ► Remove the right-hand side panel. The water pressure in the heating system can be read on the pressure gauge. As a rule of thumb (for buildings of up to three storeys), the pressure should be 1 to 2 bar for a cold system and 1.5 to 2.5 bar for a hot system. -
Page 38: Replace Pellet Suction Turbine
> 13 value) or a defined duration (in months). Notes on chimney sweep function Contact your heating engineer or the SOLARFOCUS Service Hotline > 3 – May only be performed by qualified personnel. – Do not open the boiler door during the mea- Boiler maintenance agreement surement. -
Page 39: Emission Measurement For External Boilers
16 Filling the pellet storage area 15.1 Emission measurement for external 17 Messages boilers manager- Messages that arise are shown in the eco If necessary, use the menu output test heating circuit touch control display, each message is saved in the >... - Page 40 16 Filling the pellet storage area Possible messages No. Message SO QP 50 The boiler door is open! The message in question determines who is sup- 51 Battery in operating element (display) is posed to take the required action (system operator dead SO or qualified personnel QP).
- Page 41 16 Filling the pellet storage area 7 - Flue gas sensor wrong measured value 16 - Error lambda sensor measurement The flue gas temperature sensor has a fault and must Message is triggered when the residual oxygen con- be replaced. tent in the ID fan lag is measured at over 15.5% for a period of 1.5 hours.
- Page 42 16 Filling the pellet storage area 23 - Communication with electronic module is 30 - Feed blockage interrupted The pellet auger is blocked. Too many pellets in the filling chamber of the boi- ler; often as a result of ignition faults due to improper combustion grate support, >...
- Page 43 16 Filling the pellet storage area 38 - Commissioning settings have been loaded 43 - Fault in diverter for suction heads (DFSH) During commissioning of the heating system, the This message only appears in conjunction with the customer-specific settings were saved (by qualified optional accessory Automatic diverter for suction personnel).
- Page 44 16 Filling the pellet storage area 52 - Limiting thermostat is open A fuse in the electronic module is defective ► Check fuse, replace if necessary The heating circuit limiting thermostat is open. Hea- ting water with excessive temperature was diverted to Error in the electronic module’s power supply the heating circuit.
-
Page 45: Electrical Fusing
18 Electrical fusing 74 - Differential pressure switch has triggered 18 Electrical fusing elegance This message is only possible with the pellet DANGER - There is a risk of fatal electric boiler with combustion grate, see also separate shocks when working on electrical manual DR-0138. -
Page 46: Erp Product Data Sheet
19 ErP product data sheet 19 ErP product data sheet According to Regulation (EU) 2015/1187 and 2015/1189 Manufacturer SOLARFOCUS GmbH., Werkstraße 1, 4451 St.Ulrich/Steyr elegance elegance elegance elegance pellet pellet pellet pellet Model designation Energy efficiency class Nominal heat output P 14.9... - Page 47 19 ErP product data sheet Operation manual pelletelegance...
- Page 48 Innovative makes you independent products that are easy on the envi ronment and your wallet. Everything from a single source þ _Biomass heating þ _Solar energy systems þ _Heat pumps þ _Fresh water technology Pellets Log wood + pellets Log wood Wood chips Solar energy Fresh water...
