- Page 1 Instruction Manual Shav-A-Doo Model Series: 1203 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2022 Gold Medal Products Co. Part No. 69006...
-
Page 2: Table Of Contents
Shav-A-Doo Model Series: 1203 Table of Contents SAFETY PRECAUTIONS ........................... 3 INSTALLATION INSTRUCTIONS ........................5 Inspection of Shipment ............................5 Manual ..................................5 Model Description ..............................5 Items Included with this Unit ........................... 5 Setup ................................... 5 Electrical Requirements ............................. 6 Before You Plug In Machine .......................... -
Page 3: Safety Precautions
Shav-A-Doo Model Series: 1203 SAFETY PRECAUTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle. - Page 4 Unit is for shaved ice. Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 5: Installation Instructions
Shav-A-Doo Model Series: 1203 INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). -
Page 6: Electrical Requirements
We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 7: Operating Instructions
Shav-A-Doo Model Series: 1203 OPERATING INSTRUCTIONS Controls and Their Functions POWER SWITCH Lighted Rocker Switch – supplies power to the momentary button switch. MOMENTARY SWITCH Momentary Switch must be engaged for unit to operate. Press switch to operate/energize the shaver motor; release the switch to de-energize the motor. ICE HOPPER/PUSHER HANDLE The hopper holds ice and funnels it to the shaver blades. -
Page 8: Care And Cleaning
Shav-A-Doo Model Series: 1203 Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. DO NOT clean appliance with a water jet or steam cleaner. Always unplug the equipment before cleaning or servicing. 025_051321 WARNING This machinery contains sharp blades. -
Page 9: The Following Sections Are For Qualified Service Personnel Only
Shav-A-Doo Model Series: 1203 THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle. -
Page 10: Installing New Shaver Blades
Shav-A-Doo Model Series: 1203 Installing New Shaver Blades WARNING This machinery contains sharp blades. Keep hands and body parts clear at all times. 037_103114 The section describes the procedure to replace the shaver blades. ALWAYS turn the machine OFF and unplug unit from the power supply prior to blade inspection or replacement. Use a flashlight to examine the blades in the shaver body. -
Page 11: Set Blade Height
Shav-A-Doo Model Series: 1203 14. Adjust the motor to realign with guide mark made on the cabinet in Step 3, then refasten motor mounting bolts (if unit has a hopper support and guide, it must also be reinstalled). Check the shaver head to make sure it is not rubbing against the back of the hopper and the blades are not touching the pusher handle or sides of hopper;... -
Page 12: Ordering Spare Parts
Web Page: gmpopcorn.com Replacing Broken Glass Broken glass panels can be easily replaced. Gold Medal Products Co. does not ship glass. It can be obtained from a local glass shop, always purchase tempered glass. GLASS DIMENSIONS (Height x Width x Thickness) Front Glass: 13.354”... -
Page 13: Cabinet View
Motor Cord Label (w/drain fitting) Rubber Foot *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. Part Number Part Number Item... -
Page 14: Shaver Head And Accessories
Shav-A-Doo Model Series: 1203 Shaver Head and Accessories Item Part Description Part Number SHAVER HEAD 22015 1/4-20 X 3/8 SET SC 69703 2 HOLE BLADE REPLACE SET (includes 2 blades, 22017 washers, and screws) DRAIN HOSE 3/4 ID 7/8 OD (sold by the foot) 12159 PLASTIC SNOW DIPPER 1088... -
Page 15: Wiring Diagram
Shav-A-Doo Model Series: 1203 Wiring Diagram Model 1203-00-000 gmpopcorn.com Page 15... - Page 16 Shav-A-Doo Model Series: 1203 Model 1203-01-000 gmpopcorn.com Page 16...
-
Page 17: Warranty
