- Page 1 INSTALLATION - MAINTENANCE VS 100 Guide rail VS 100 Wire...
- Page 2 • Opening windows and doors may limit the possibility for installing screens. • The motor and any control equipment must be installed by an authorised electrician. VS 100 Guide rail - installing wall brackets and cassette Pull the tape through the drilled hole...
- Page 3 VS 100 Installation - Maintenance Installation - Maintenance VS 100 Wire - Assembling wall brackets and cassette VS 100 Guide rail - installing cassette support (optional) Screw the cassette support (optional) Center the cassette above the window and to the wall.
- Page 4 Screen Screen VS 100 VS 100 Installation - Maintenance Installation - Maintenance VS 100 Wire - Assembling the tensioning brackets VS 100 Wire -Interior tape operation Roll down the fabric to the desired bottom Center the cassette above the window. Mark position - assemble the tensioning brackets the bottom, left and right side.
- Page 5 Screen Screen VS 100 VS 100 Installation - Maintenance Installation - Maintenance VS 100 Wire - Interior tape operation Finish the installation by carefully lower the front profi le to the desired end posi- tion - move the tassel to the top and make a knot directly under the tassel.
- Page 6 The original document may not be altered in text or version without the consent of Hunter Douglas Scandinavia www.hunterdouglas.se Hunter Douglas • Alingsås • Sweden Tel: +46-322 775 00 • E-mail: order@hunterdouglas.se ® Registered Trademark of Hunter Douglas Scandinavia, Sweden © Hunter Douglas 4-2021...
