The device can be mounted in several ways: wall, ceiling, pole. To tighten the device to a pole, use the provided metal hose clamp.
Guide the loop around the device through the provided holes, and around the pole where it will be mounted, or use a DIN mount to attach the device to a
rail:
You should avoid connecting a loose Ethernet cable to the Ethernet port, secure the cable to a wall or the pole, so that the cable weight is not pulling the
port. It is recommended to secure the Ethernet cable less than 2m from the device. This is to ensure that the cable doesn't damage the port by its weight,
or doesn't fall out. It is possible to connect grounding wires to the PCB board mounting holes, but to do this, you must remove the PCB from the case.
Warning! This equipment should be installed and operated with a minimum distance of 380 cm between the device and your body. Operation of
this equipment in the residential environment could cause radio interference.

Powering

The device accepts power from the power jack or from the Ethernet port:
Direct-input power jack (5.5mm outside and 2mm inside, female, pin positive plug) accepts 24 V DC.
Ethernet port accepts passive Power over Ethernet 18-57 V DC (Please compensate voltage for loss due to cable length)
The power consumption under maximum load can reach 12 W. For BaseBox 6 model up to 23 W.

Configuration

RouterOS includes many configuration options in addition to what is described in this document. We suggest
starting here to get yourself accustomed to the possibilities:
the Winbox tool ( https://mt.lv/winbox
(all access is blocked from the Internet port by default).
For recovery purposes, it is possible to boot the device from the network, see a section

Expansion Slots and Ports

BaseBox 2 model - 2.4 GHz, 802.11b/g/n.
BaseBox 5 model - 5 GHz, 802.11a/n.
BaseBox 6 model - 6 GHz, 802.11a/n.
One 10/100/1000 Gigabit Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either straight or
crossover cable for connecting to other network devices.
USB type-A slot.
One miniPCIe slot. This device might be incompatible with the R11e-LTE international modem.

The miniPCI-e slot usage

https://mt.lv/help
) can be used to connect to the MAC address of the device from the LAN side
. In case IP connection is not available,
Reset button .
