cAP ac
cAP ac
The cAP (
RBcAPGi-5acD2nD
) ac is a ceiling mountable wireless access point. It is already configured, you can simply plug in your ISP cable and start
using wireless Internet.
Connecting
Remove metal ring see
Connect POE to the Ethernet port 1, please see the
Set your computer IP configuration to
The device wireless access point mode is enabled by default.
The device will boot up and Wireless network will be available for connecting.
Open network connections on your PC, mobile phone, or other device and search for MikroTik wireless network and connect to it.
Once connected to the wireless network, open
no password by default, you will be logged in automatically.
We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best
performance and stability.
Choose your country, to apply country regulation settings, and set up your password on the screen that loads.
Removing mounting ring
The Mounting ring comes installed on the device, in order to access Ethernet ports please remove it by turning it counterclockwise and the ring will be
released.
Powering
cAP ac#Removing mounting ring
cAP ac#Powering
automatic
(DHCP).
https://192.168.88.1
;
section for instructions on how to connect POE.
in your web browser to start configuration, user name: admin, since there is

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the cAP ac and is the answer not in the manual?

Questions and answers

Summary of Contents for MikroTik cAP ac

  • Page 1 The device will boot up and Wireless network will be available for connecting. Open network connections on your PC, mobile phone, or other device and search for MikroTik wireless network and connect to it. Once connected to the wireless network, open https://192.168.88.1...
  • Page 2 The device accepts power from the Ethernet port, so you must either use the included passive PoE injector or make sure your switch supports passive or 802.3af/at PoE output. Ethernet port accepts 12-57 V DC (802.3af/at or passive PoE). The power consumption under maximum load can reach 13 W. Connecting to a POE Adapter: Connect the Ethernet cable from the device to the POE port of the POE adapter.
  • Page 3: Expansion Slots And Ports

    LAN side (all access is blocked from the Internet port by default). For recovery purposes, it is possible to boot the device from the network, see a section cAP ac#Reset button Expansion slots and ports Two 10/100/1000 Ethernet ports, supporting automatic cross/straight cable correction (Auto MDI/X).
  • Page 4: Specifications

    Other operating systems have not been tested. MikroTik mobile app Use the MikroTik smartphone app to configure your router in the field, or to apply the most basic initial settings for your MikroTik home access point. Scan QR code and choose your preferred OS.
  • Page 5: Federal Communication Commission Interference Statement

    Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039. BG С настоящото Mikrotīkls SIA декларира, че този тип радиосъоръжение RouterBOARD е в съответствие с Директива 2014/53/ЕС. Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: https://mikrotik.com/products...
  • Page 6 CS Tímto Mikrotīkls SIA prohlašuje, že typ rádiového zařízení RouterBOARD je v souladu se směrnicí 2014/53/EU. Úplné znění EU prohlášení o shodě je k dispozici na této internetové adrese: https://mikrotik.com/products DA Hermed erklærer Mikrotīkls SIA , at radioudstyrstypen RouterBOARD er i overensstemmelse med direktiv 2014/53/EU. EU- overensstemmelseserklæringens fulde tekst kan findes på...
  • Page 7: Mpe Statement

    LV Ar šo Mikrotīkls SIA deklarē, ka radioiekārta RouterBOARD atbilst Direktīvai 2014/53/ES. Pilns ES atbilstības deklarācijas teksts ir pieejams šādā interneta vietnē: https://mikrotik.com/products MT B'dan, Mikrotīkls SIA , niddikjara li dan it-tip ta' tagħmir tar-radju RouterBOARD huwa konformi mad-Direttiva 2014/53/UE. It-test kollu tad- dikjarazzjoni ta' konformità...
  • Page 8 * It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed! Note. The information contained here is subject to change. Please visit the product page on www.mikrotik.com...
