BIO-MED DEVICES IC-2A Service Manual page 43

PATIENT
21
MAX. PRESSURE
CAUTION:
THE CIRCUIT W ILL NOT
PRESS URIZE WITH THIS
KNO B AT THE FULL CW
POSITIO N.
WARNING:
CLEAN, DRY 50±5 PSI REGULATED SOURCES OF MEDICAL GRADE OXYGEN & AIR
MUST BE USED OR MALFUNCTION CAN RESULT. OXYGEN CONCENTRATION OF
POWER SUPPLY GAS AND/OR ALTITUDE AFFECT TIMING ACCURACY. CONSULT
THE INSTRUCTION MANUAL FOR CORRECTION FACTORS.
CAUTION:
FEDERAL LAW RESTRICTS THIS DEVICE TO SALE BY OR ON THE ORDER OF A
PHYSICIAN.
BEFORE OPERATING THIS INSTRUMENT, READ THE INSTRUCTION
!
MANUAL THOROUGHLY. PARTICULAR ATTENTION SHOULD BE GIVEN
TO THE USE OF THE DEMAND MODE.
0086
13 15
14
LOGIC GAS
SUPPLY
HOSE
100% O
50±5 PSI
345±34.5 kPa
30 LPM MAX. FLOW
PRESSURE
GAUGE
DATE OF MFR.
BIO−MED DEVICES, INC.
GUILFORD, CT U.S.A.
Fig. 6-2
16 17
PATIENT GAS
SUPPLY
AIR/OXYGEN
2
50±5 PSI
345±34.5 kPa
82 LPM MAX. FLOW
EXHALATION
VALVE
REF
SN
20
41
