DESCRIPTION

INTRODUCING THE IC-2A VENTILATOR

The IC-2A Ventilator (Figure 1-1) is a highly sophisticated, precision, pneumatic, life
support device, built to rigid specifications.
The IC-2A Ventilator is designed for respiratory support of adult patients both in a
health-care facility and during transport. It can be operated within volume or pressure
limits and has a wide range of inspiratory/expiratory time ratios (I/E). Its compact
lightweight design permits hand-carrying or attachment to a stand thus facilitating
uninterrupted support during transport.
The IC-2A Ventilator is compatible with masks and endotracheal and tracheotomy
tubes. It is gas-powered using either a portable pressurized tank or wall outlet providing
50 psi oxygen or air.
constantly self-purging case. Miniature pneumatic logic control elements produce high
reliability due to negligible frictional wear.
standard accessories: humidifier, oxygen blender, oxygen analyzer, pressure alarm
and patient circuit.

Controls, Indicators and Connectors

a. Front Panel – Table 1-1 lists the IC-2A Ventilator front panel controls and
indicators and their functions. Refer to Figure 1-1.
b. Top and Back Panel Controls and Connectors – Table 1-2 lists the IC-2A
Ventilator top and back panel controls and connectors and their functions.
Refer to Figure 1-2.
Table 1-1. IC-2A Ventilator Front Panel Controls and Indicators
Control or Indicator
CYCLE/MANUAL CPAP switch
INSPIRATORY TIME control
EXPIRATORY TIME control
FLOW RATE control
INSPIRATORY EFFORT control
PEEP/CPAP control
It is non-electric, presents no shock hazard and features a
Two-position toggle switch for selecting non-cycling
(Manual CPAP) or time-cycled (CYCLE) modes of
operation
Rotary control for setting inspiratory time in time-
cycled modes; calibrated from .4 to 2 seconds.
Rotary control for setting expiratory time in time-
cycled modes; calibrated from .5 to 4 seconds and
may be set to 45 seconds or more in IMV range.
Rotary control for setting flow rate; calibrated from
20 to 75 lpm.
Rotary
sensitivity
Rotary control for setting PEEP level when
CYCLE/MANUAL CPAP switch is set to CYCLE or
for setting CPAP level when CYCLE/MANUAL
CPAP switch is set to MANUAL CPAP
The IC-2A Ventilator is compatible with
Function
control for adjusting patient trigger
