BIO-MED DEVICES IC-2A Service Manual page 26

RATE & I/E RATIO
.50
.60
.75
1.00
1.50
2.00
4.00
TIDAL VOLUME
20
30
40
50
60
70
75
INSPIRATORY TIME (SEC.)
.40 .50
67 60
1:1.3 1:1
60 55
1:1.5 1:1.2
52 48
1:1.9 1:1.5
43 40
1:2.5 1:2
32 30
1:3.8 1:3
25 24
1:5 1:4
14 13
1:10 1:8
Fig. 3-1
INSPIRATORY TIME (SEC.)
.40 .50
130 170
200 250
270 330
330 420
400 500
470 580
500 630
Fig. 3-2
.75 1.00
48 40
1.5:1 2:1
44 38
1.3:1 1.7:1
40 34
1:1 1.3:1
34 30
1:1.3 1:1
27 24
1:2 1:1.5
22 20
1:2.7 1:2
13 12
1:5.3 1:4
.75 1.00
250 330
375 500
500 670
630 830
750 1000
875 1170
940 1250
1.50 2.00
30 24
3:1 4:1
29 23
2.5:1 3.3:1
27 22
2:1 2.7:1
24 20
1.5:1 2:1
20 17
1:1 1.3:1
17 15
1:1.3 1:1
11 10
1:2.7 1:2
1.50 2.00
500 670
750 1000
1000 1330
1250 1670
1500 2000
1750 2330
1880 2500
24
