BIO-MED DEVICES IC-2A Service Manual page 12

Table 1-3. IC-2A Specifications and Limitations
Specification/Limitation
Logic Oxygen
Patient Supply
Inspiratory Time (Calibrated*)
Expiratory Time (Calibrated*)
*INSPIRATORY and EXPIRATORY TIME controls are calibrated at sea level and 20°C using USP
oxygen. Changes in barometric pressure, altitude changes, or use of diluted oxygen will affect time
calibration.
Table 1-3. IC-2A Specifications and Limitations (continues)
Specification/Limitation
Rate
SIMV Backup Rate
I/E Ratio
Flow Rate (Calibrated)
Tidal Volume
PEEP/CPAP
System Pressure Gauge
Visual Indicators
Two-Way Relief Valve
Adjustable Maximum
Pressure Valve
Inspiratory
Sensitivity Range
Logic Gas Consumption
Dimensions
Weight
Storage Temperature:
Operating Temperature:
Clean, dry, medical grade 50 ±5 psi oxygen
Clean, dry, oil-free, 50 ±5 psi patient breathing gas
mixture
0.4 to 2.0 seconds
0.5 to 4.0 seconds (variable to 45 seconds or more,
uncalibrated, in the IMV range)
1-1/3 to 66 bpm
4-2/3 to 6-3/4 bpm
Infinitely Adjustable
0 to 75 lpm
0 to >3000 ml
0 to 25 ±5 cmH
-10 to +120 cmH
Cycle; Demand
Internally installed valve opens above 120 ±20 cmH
below -4±1 cmH
0 to 120 cmH
Effort -0.5 to –10.0 cmH
12 LPM (approx.); varies with control settings; higher
pressure increases consumption
3-3/8" X 6-1/8" X 10-1/4"
(8.57 X 15.56 X 26.14 cm)
9 lbs approx. (4.1 kg)
32° to 122°F (0°to 50°C)
14° to 122°F (10°to 50°C)
Range
Range
O
2
O; ±3% full scale accuracy
2
O
2
O
2
O
2
O or
2
10
