Arista 750 Series Quick Start Manual

Modular cognitive campus switches
Hide thumbs Also See for 750 Series:
Table of Contents

Advertisement

Quick Links

Quick Start Guide
750 Series Modular
Cognitive Campus Switches
Arista Networks
www.arista.com
DOC-04730-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 750 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Arista 750 Series

Summary of Contents for Arista 750 Series

  • Page 1 Quick Start Guide 750 Series Modular Cognitive Campus Switches Arista Networks www.arista.com DOC-04730-02...
  • Page 2 © Copyright 2022 Arista Networks, Inc. The information contained herein is subject to change without notice. Arista Networks and the Arista logo are trademarks of Arista Networks, Inc in the United States and other countries. Other product or service names may be trademarks or service marks of others.

  • Page 3: Table Of Contents

    Contents Contents Chapter 1: Overview................1 1.1 Scope............................1 1.2 Receiving and Inspecting the Equipment................1 1.3 Installation Process.........................1 1.4 Safety Information........................2 1.5 Obtaining Technical Assistance..................... 2 1.6 Specifications.......................... 3 Chapter 2: Preparation................5 2.1 Site Selection..........................5 2.2 Tools and Parts Required for Installation................6 2.3 Electrostatic Discharge (ESD) Precautions................
  • Page 4 A.8.1 Linecard Module Status LEDs Behavior..............37 A.8.2 Linecard Module Status LED................. 37 A.9 Switchcard Module Status Indicators...................38 A.9.1 Switchcard Module Status LEDs Behavior.............39 A.9.2 Switchcard Module Status LED................39 A.9.3 Switchcard Module Active Status LED..............40 A.10 Fan Module Status Indicators.................... 40 A.11 Power Supply Status Indicators..................

  • Page 5: Chapter 1: Overview

    Inspect the packing list and confirm that you received all listed items. Compare the packing list with your 750 Series Modular Switches purchase order. Parts List provides a list of components included with the switch.

  • Page 6: Safety Information

    Refer to the Arista Networks document Safety Information and Translated Safety Warnings available at: https://www.arista.com/en/support/product-documentation. Obtaining Technical Assistance Any customer, partner, reseller or distributor holding a valid Arista Service Contract can obtain technical support in any of the following ways: •...

  • Page 7: Specifications

    Overview Specifications Modular Switch Specifications lists the specifications of Arista Data Center modular switches covered by this guide. Table 1: Modular Switch Specifications CCS-755 CCS-758 Height 7 RU: 305 mm (12.0 inches) 10 RU: 439.4 mm (17.3 inches) Width 441 mm (17.36 inches) 441 mm (17.36 inches)
  • Page 8 755 Series System Full chassis 1026 W / 1251 W 18871 W loaded with 2 CCS-750-Sup100 2 CCS-755-X3-SC 5 CCS-750X-48ZP 6 PWR-3351-AC-RED 758 Series System Full chassis 1338 W / 1566 W 31789 W loaded with 2 CCS-750-Sup100 2 CCS-755-X3-SC 8 CCS-750X-48ZP 10 PWR-3351-AC-RED Assumes all PSUs are operating between 220 - 240 V.

  • Page 9: Chapter 2: Preparation

    Chapter 2 Preparation The following topics are covered in this section: • Site Selection • Tools and Parts Required for Installation • Electrostatic Discharge (ESD) Precautions Site Selection The following criteria should be considered when selecting a site to install the switch. •...

  • Page 10: Tools And Parts Required For Installation

    Note: The accessory kit provides the required mounting hardware for each switch. • Power Requirements: Arista switches require a minimum number of operating power supplies in all chassis, and for each power domain of switches with multiple power domains. Refer to...

  • Page 11: Electrostatic Discharge (Esd) Precautions

    Preparation The accessory kit includes screws that fit many common equipment racks. Rack nuts are only for racks with unthreaded, rack-post holes. Electrostatic Discharge (ESD) Precautions Observe these guidelines to avoid ESD damage when installing or servicing the switch. • Assemble or disassemble equipment only in a static-free work area.

  • Page 13: Chapter 3: Rack Mounting The Switch

    Chapter 3 Rack Mounting the Switch The following topics are covered in this section: • Two-post Rack Mount • Four-post Rack Mount (Optional) The switches can be installed in two-post Two-post Rack Mount or four-post Four-post Rack Mount (Optional) racks. The appropriate accessory kit provides components for installing the switch in the rack.
  • Page 14 3.1.1.1 Attaching Mounting Brackets to the CCS-755 Attach the mounting brackets to both sides of the chassis using the screws provided in the kit for the desired orientation and position. The following figure shows the CCS-755 chassis with the mounting brackets for Forward-Front, Forward-Center, and Backward-Front mounting.

  • Page 15: Rack Mounting The Ccs-758

    Rack Mounting the Switch Figure 4: Inserting the Switch into the Two-post Rack Note: shows an unthreaded rack example with rack nuts. 3. Secure the chassis to the rack using the screws. Figure 5: Securing the chassis (755 Forward-Front) After completing the two-post Installation, proceed to Cabling the Modular Switch.
  • Page 16 3.1.2.1 Attaching Mounting Brackets to the CCS-758 Attach the mounting brackets to both sides of the chassis using the screws provided in the kit for the desired orientation and position. The following figure shows the CCS-758 chassis with the mounting brackets for Forward-Front, Forward-Center, and Backward-Front mounting.

  • Page 17: Four-Post Rack Mount (Optional)

    Rack Mounting the Switch Figure 8: Inserting the Switch into the Two-post Rack (758 Forward-Front) 3. Secure the chassis to the rack as shown in the following figure. Figure 9: Securing the Chassis (758 Forward-Front) After completing the two-post Installation, proceed to Cabling the Modular Switch.

  • Page 18: Rack Mounting The Ccs-755

    • mounting brackets • 18 screws 3.2.1 Rack Mounting the CCS-755 To mount the switch to the rack, perform the following tasks. • Attach the mounting brackets to the switch for the desired orientation and position supported Attaching Mounting Brackets to the CCS-755 •...
  • Page 19 Rack Mounting the Switch Figure 11: Attaching Mounting Screws to the Rack Posts for 755 2. Buckle the straps on the cradle together, prior to installation, so the left and right sides are angled slightly inwards for the figure below. Figure 12: Buckling the Straps 3.
  • Page 20 Figure 13: Inserting the Cradle 6. Release the clasp on the connector to rotate the left and right sides so they are vertical for the figure below. Figure 14: Aligning the Cradle in the Rack 7. Secure the cradle to the rack posts using the remaining screws, and tighten the loosely mounted screws for the figure below.

  • Page 21: Rack Mounting The Ccs-758

    Rack Mounting the Switch 3.2.1.3 Inserting and Securing the Switch into the Rack for Four-post 755 1. Move the chassis to the rack using a mechanical lift. Note: If modules are inserted in the chassis, use the lift carefully to avoid damaging any components.
  • Page 22 • Insert and secure the switch into the rack Inserting and Securing CCS-758 Chassis into Rack. 3.2.2.1 Attaching Mounting Brackets to the Four Post CCS-758 Attach the mounting brackets to both sides of the chassis using the screws provided in the kit for the desired orientation and position.
  • Page 23 Rack Mounting the Switch Figure 20: Figure 3-19: Buckling the straps 3. Pull out the rear sliding rails slightly beyond the back rack posts. 4. Insert the cradle so that the notches in the cradle engage behind the loosely mounted front screws for the figure below.
  • Page 24 Figure 23: Figure 3-22: Securing the cradle in the rack 3.2.2.3 Inserting and Securing the Switch into the Rack for Four Post CCS-758 Note: If modules are inserted in the chassis, use the lift carefully to avoid damaging any components. 1.
  • Page 25 Rack Mounting the Switch Figure 25: Securing the Chassis (758 Forward-Front) After completing the Four-Post Installation, proceed to Cabling the Modular Switch...

  • Page 27: Chapter 4: Cabling The Modular Switch

    • Connecting Linecard Modules and Cables Cabling the Power Supplies Before you begin, refer to the Arista Networks document Compliance and Safety Guide available at: https://www.arista.com/en/support/product-documentation Important: Power down the switch: Remove all power cords from the power inlets. Mettez le commutateur: Retirez tous les cordons d'alimentation des prises d'alimentation.

  • Page 28: Cabling Chassis Ground

    CCS-758 Each power supply includes a fan that maintains proper power supply temperature. The appendices display the location of components for all switches described in this guide. Cabling Chassis Ground Figure 26: Chassis Ground Locations (CCS-755) Figure 27: Chassis Ground Locations (CCS-758) display the location of the chassis grounding locations on the front panel of the switches.

  • Page 29: Cabling The Ac Power Supplies

    Cabling the Modular Switch Figure 27: Chassis Ground Locations (CCS-758) 1 Grounding locations 3 Line cards 2 ESD attach point 4 Supervisor modules To power down the switch, remove all power cords from the power inlets. Cabling the AC Power Supplies The switches use PWR-3351-AC-RED (Figure 28: AC Power Supply (PWR-3351-AC-RED)) AC power...

  • Page 30: Power Supply Specifications

    Rear Panel displays the rear panel location of the power supplies. Note: After disconnection from main power, LED(s) on the PSU remain on for a short period of time. The actual duration varies for each PSU model, but the LED(s) will eventually turn off. The PSU fan will ramp up and run at maximum speed for a few seconds before shutting down.

  • Page 31: Connecting Supervisor Cables

    Cabling the Modular Switch The recommended installation is to wire each supply to independent power feed (A or B). Each power supply includes a fan that maintains proper power supply temperature. The following appendices display the location of the following component on all switches described in this guide. Front Panel displays the front panel location of the supervisor modules and line cards.

  • Page 32: Connecting Linecard Modules And Cables

    2 Supervisor active status 6 Fan status LED 10 RJ-45 Serial management port 3 PSU status LED 7 Uplink status LED 11 USB Port 4 Linecard status LED 8 Supervisor/Uplink ports (4x 12 Release SFP25) • Console (Serial) Port: Connect to a PC with RJ-45 to DB-9 serial adapter cable. Default switch settings include: •...
  • Page 33 Flexion excessive peut endommager les câbles d'interface, en particulier les câbles optiques. Note: You must ensure that any open slots for modules, supervisors, linecards, etc. are covered by the appropriate “blank” plates. Check with your local Arista Networks representative if you have questions.

  • Page 35: Chapter 5: Configuring The Modular Switch

    Chapter 5 Configuring the Modular Switch Arista switches ship from the factory in Zero Touch Provisioning (ZTP) mode. ZTP configures the switch without user intervention by downloading a startup configuration file or a boot script from a location specified by a DHCP server. To manually configure a switch, ZTP is bypassed. The initial configuration provides one username (admin) accessible only through the console port because it has no password.
  • Page 36 11. When the management port IP address is configured, use this command to access the switch from a host, using the address configured in Step 9. ssh admin@192.0.2.8 Refer to the Arista Networks User Manual for complete switch configuration information.

  • Page 37: Appendix A: Status Indicators

    Appendix A Status Indicators The following topics are covered in this section: • Supervisor Module • Linecard Module Indicators • Switchcard Module Status Indicators • Fan Module Status Indicators • Power Supply Status Indicators Supervisor Module While the front panel of each switch can house two supervisors, switch operations require only one.

  • Page 38: Supervisor Status Leds Behavior

    Figure 33: Supervisor CCS-750-SUP25 1 Supervisor status LED 5 Switch card status LED 9 Ethernet management ports 2 Supervisor active status 6 Fan status LED 10 RJ-45 Serial console port 3 PSU status LED 7 Uplink status LED 11 USB Port 4 Linecard status LED 8 SFP25 uplink ports 12 Release/locking...

  • Page 39: Linecard Status Led

    Status Indicators Table 10: PSU Status LED States State Status PSU not detected, installed or powered. Green All installed PSUs are operating normally. One or more PSU has a fault. Linecard Status LED Table 11: Linecard Status LED States interprets the states of the Linecard status LED. Table 11: Linecard Status LED States State Status...

  • Page 40: Management Ethernet Port Status Led

    Table 13: Fan Status LED States State Status No fan detected. Green All installed fans are operating normally. Yellow/Amber/Orange One or more fans has failed or is missing. Fans are insufficient or incompatible. Management Ethernet Port Status LED Table 14: Management Ethernet Port Status LED States interprets the states of the management Ethernet port status LED.

  • Page 41: Linecard Module Indicators

    Status Indicators Linecard Module Indicators Each linecard module provides one status LED plus LEDs for each port on the card.Figure 34: Linecard Module Status LEDs shows a representative line card. The figures in Linecards indicate the location of the LEDs on each linecard. Figure 34: Linecard Module Status LEDs 1 Linecard module status 2 Port status LED...

  • Page 42: Switchcard Module Status Indicators

    Blinking Yellow/Amber/Orange Locater function is enabled (Beacon). Switchcard Module Status Indicators Rear Panel displays the position of the Switch Card Module Status LEDs on the rear of each switch. 755 Switchcard Module and Fan Module Status LEDs displays fan module status and switch card module status LEDs on the 755 switch.

  • Page 43: Switchcard Module Status Leds Behavior

    Status Indicators Figure 36: 758 Switchcard Module and Fan Module Status LEDs 1 Fan module 1 status LED 4 Switchcard release 7 Switchcard release 2 Fan module 1 5 Switchcard module status 3 Fan module 1 release 6 Switchcard module active status LED A.9.1 Switchcard Module Status LEDs Behavior...

  • Page 44: Switchcard Module Active Status Led

    Table 18: Switchcard Module Status LED States State Status Switchcard does not have power. Green All installed switchcards are working normally. Yellow/Amber/Orange Switchcard is booting up or being updated. One or more switchcards have failed. A.9.3 Switchcard Module Active Status LED Switchcard Module Active Status LED States interprets the states of the switch card module active status LED.

  • Page 45: Power Supply Status Indicators

    Status Indicators Green Fan module is working normally. Flashing red Locater function is enabled (Beacon). Fan module has failed. A.11 Power Supply Status Indicators The power supply status LED ison the power supply modules.Figure 38: AC Power Supply (PWR-3351-AC-RED) displays the LED on the PWR-3351-AC-RED AC power supply. Figure 38: AC Power Supply (PWR-3351-AC-RED) 1 Status LED 2 Handle...

  • Page 47: Appendix B: Parts List

    Optional Optional CCS-750-4PL) Optional Power Cords Warning: All provided power cables are for use only with Arista products. Câbles d’alimentation doivent être utilisés uniquement avec des produits de Arista. Parts Used in All Rack Mount Configurations B.1.1 Cables Table 23: Cables Provided in Accessory Kit...

  • Page 48: Getting-Started Booklet

    RJ45 To DB9 Adapter with a 6-foot rolled cable. Seven-foot RJ45 Patch panel cable. B.1.2 Getting-Started Booklet One 2-page document. Two-Post Rack Mount Parts The following sections list the parts provided in the accessory kit for two-post rack mount installations. Table 24: Two-Post Rack Mount Parts Quantity Description...

  • Page 49: Four-Post (Extended Depth) Rack Mount Parts (Optional)

    Parts List Table 25: Four-Post Rack Mount Parts Quantity Description Cradle assembly. Mounting brackets/ears (flange). Rack mounting screws and rack nuts Flat-head screws Figure 40: Four-Post Rack Mount Parts 1 Mounting brackets/ears 3 Rack mounting screws and rack nuts 2 Cradle assembly Four-Post (Extended Depth) Rack Mount Parts (Optional) The following sections list the parts provided in the accessory kit for four-post rack mount installations.
  • Page 50 Figure 41: Four-Post Rack Mount Parts 1 Mounting brackets/ears 3 Rack mounting screws and rack nuts 2 Cradle assembly...

  • Page 51: Appendix C: Front Panel

    Appendix C Front Panel This appendix displays the front panel of all switches covered by this guide. Figure 42: CCS-755 Front Panel (Fully Populated) 1 Grounding locations 4 Supervisor modules 2 ESD attach point 3 Line cards...
  • Page 52 Figure 43: CCS-758 Front Panel (Fully Populated) 1 Grounding locations 4 Supervisor modules 2 ESD attach point 3 Line cards...

  • Page 53: Appendix D: Rear Panel

    Appendix D Rear Panel This appendix displays the rear panel of all switches covered by this guide. Figure 44: CCS-755 Rear Panel (Fully Populated) Chassis ground Fans and switchcard module 2 11 ESD attachment point PSUs (1, 3, 5 - From top) Switchcard ejector - SC2 12 Switchcard ejector - SC2 Fans and switchcard module 1...
  • Page 54 Figure 45: CCS-758 Rear Panel (Fully Populated) Chassis ground Fans and switchcard module 2 11 ESD attachment point PSUs (1, 3, 5, 7, 9 - From top) Switchcard ejector - SC2 12 Switchcard ejector - SC2 Fans and switchcard module 1 Ejector latch - SC2 13 Ejector latch - SC2 Switchcard ejector - SC1...

  • Page 55: Appendix E: Linecards

    Appendix E Linecards This appendix displays the linecards supported by modular switches covered by this guide. Figure 46: CCS-750X-48ZXP Table 27: Linecard status LED Port numbers Port status LED Note: Ports 5 to 16, 21 to 32, and 37 to 48 are 100M-capable ports. Figure 47: CCS-750X-48TP 1 Linecard status LED 3 Port numbers...

  • Page 57: Appendix F: Maintenance And Field Replacement

    Appendix F Maintenance and Field Replacement The following topics are covered in this section: • Power Supplies • Fan Module • Supervisor Module • Linecards • Switchcards This appendix describes the process for replacing switch components. You must ensure that at least one of the secondary grounding pads located on the front panel of the chassis is connected to the data center ground.

  • Page 58: Installing Ac Power Supply

    F.1.2 Installing AC Power Supply You must make space for installing the power supply by removing an existing one (Removing AC Power Supply) or use an available slot on the switch. Perform the following steps to install an AC power supply. 1.

  • Page 59: Removing Supervisor Module Blank

    Maintenance and Field Replacement F.3.2 Removing Supervisor Module Blank The supervisor module blank has plastic latches. 1. Put on a grounded, anti-static ESD strap. 2. Grip the plastic handles to release the latch and remove the blank from the supervisor module slot you are going to populate.

  • Page 60: Removing A Linecard

    Linecard Ejector lever (linecard seated correctly) Ejector mechanism (lever Ejector lever (linecard not and handle) seated) F.4.1 Removing a Linecard Perform the following steps to remove a linecard. 1. Put on a grounded, anti-static ESD strap. 2. Move the left and right handle outwards until the ejector lever releases the linecard. 3.

  • Page 61: Installing Switchcard

    Maintenance and Field Replacement Figure 50: 758 Rear View with one Switchcard Installed 1 SC2 cover F.5.2 Installing Switchcard You must make space for installing the switchcard by removing an existing one from a switchcard slot available on the switch unless an open slot is available. 1.

  • Page 63: Appendix G: Regulatory Model Numbers

    Appendix G Regulatory Model Numbers This appendix lists the Regulatory Model Numbers (RMNs), where applicable, for the product models for the switches described in this document. Table 28: Regulatory Model Numbers and Product Numbers Regulatory Model Number Product Number(s) (RMN) CCS-755 CCS-755 CCS-758...

  • Page 65: Appendix H: Taiwan Rohs Information

    Appendix H Taiwan RoHS Information This appendix provides Taiwan RoHS information for switches covered by this guide. For Taiwan BSMI RoHS Table, go to https://www.arista.com/assets/data/pdf/AristaBSMIRoHS.pdf.
