INSTRUCTIONS MUST BE KEPT AFTER INSTALLATION
Models - Tyrell / Kiruna / Linnea
Always read this manual first before attempting to install or use this
fireplace. For your safety, always comply with all warnings and safety
instructions contained in this manual to prevent personal injury or
Please note: Once your E-Smart product has been installed and
switched ON, the fireplace will take approximately 10 seconds to power
INSTRUCTION MANUAL ISS. 3
INSTRUCTION MANUAL ISS. 3
Halo Instruction Guide
FOR FUTURE MAINTENANCE
Important Safety Information
up. This is a normal operating procedure and NOT a fault.
Product
Information
ENGLISH
property damage.
SERIAL NUMBER LABEL
1
Advertisement
Table of Contents
Related Manuals for Evonicfires Halo Tyrell
Summary of Contents for Evonicfires Halo Tyrell
- Page 1 Halo Instruction Guide INSTRUCTIONS MUST BE KEPT AFTER INSTALLATION FOR FUTURE MAINTENANCE Models - Tyrell / Kiruna / Linnea Important Safety Information Always read this manual first before attempting to install or use this fireplace. For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage.
-
Page 2: Table Of Contents
CONTENTS Electrical Safety................. 3 Installation................. 5 Installation Requirements..........6 Converting to GF / GF2 / GF3..........7 Installation Process............8 Installing the Side Panels / Converting to GF / GF2..... 9 Installation Guide............... 10 Installation Method............12 Installing the Side Chrome Panels........11 Log Layouts................ -
Page 3: Electrical Safety
ELECTRICAL SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all instructions before using this electric fireplace. 2. This fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. The trim around the heater outlet becomes hot during heater operation. - Page 4 13. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage to the heater. 14. To prevent a possible fire, do not block air intakes or exhaust in any manner. 15.
-
Page 5: Installation
INSTALLATION INSTALLATION INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... -
Page 6: Installation Requirements
INSTALLATION REQUIREMENTS Review and consider all the following conditions before installation: Ensure installation does not allow the electric fireplace to be in direct contact with building vapour barrier or insulation and meets all local building code. A 15 Amp, 120 Volt circuit is required. A dedicated circuit is preferred but not essential in all cases. -
Page 7: Converting To Gf / Gf2 / Gf3
CONVERTING TO GF / GF2 / GF3 The appliance is shipped in the GF3 configuration, however most models can be converted to be GF or GF2 depending on your preference. GF Configuration Glass Fronted A single glass panel at the front of the appliance. -
Page 8: Installation Process
INSTALLATION PROCESS Evoflame Model Evoflame Model (GF2) (GF2) (GF) (GF) (GF3) (GF3) Front & Front & Glass Glass Front & Front & 1 Glass Side 1 Glass Side Fronted Fronted 2 Glass Sides 2 Glass Sides Fit 2 Side Panels Fit 2 Side Panels Fit 1 Side Panel Fit 1 Side Panel... -
Page 9: Installing The Side Panels / Converting To Gf / Gf2
INSTALLING THE SIDE PANELS / CONVERTING TO GF / GF2 Unscrew and remove the plaster kits from the side/s of the appliance. Screw in the side panel/s, on one or both sides. INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... -
Page 10: Installation Guide
INSTALLATION GUIDE INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... - Page 11 INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3...
-
Page 12: Installation Method
INSTALLATION METHOD PLEASE NOTE: It is crucial to ensure that the product has a minimum internal clearance directly below the vents of 2”(50mm), this is to ensure that the product can circulate the required airflow for the heater unit. Any faults as a result of ignoring the installation guidelines will invalidate the warranty. This product has been designed to be installed into a plaster board, or existing masonry chimney breast. -
Page 13: Installing The Side Chrome Panels
INSTALLING THE SIDE CHROME PANELS Alternatively, the chrome side panels can be attached to the case with the magnets as shown below. Ensure that the magnets are positioned with the short side touching the case. INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... -
Page 14: Log Layouts
LOG LAYOUTS LOG LAYOUTS INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... - Page 15 LOG SET GUIDANCE Please note: Log sets can be arranged to suit personal preference MODEL LOG SET & QUANTITY Tyrell E800 Split Log Set x 1 (5 Logs) Kiruna E1030 Log Set x 1 (7 Logs) Linnea E1500 Log Set x 1 (8 Logs) E800 LOG SET x 1 –...
-
Page 16: Installing The Side Glass Panels
INSTALLING THE SIDE INSTALLING THE SIDE GLASS PANELS GLASS PANELS INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... - Page 17 INSTALLING THE SIDE GLASS PANELS Unscrew and remove the top and bottom glass retainer panels. Slide in the side glass pieces. INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3...
-
Page 18: Installing The Front Glass Panel
INSTALLING THE FRONT INSTALLING THE FRONT GLASS PANEL GLASS PANEL INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... - Page 19 INSTALLING THE FRONT GLASS PANEL Apply the Suction cup to the glass and position the bottom edge of the glass first, then pivot the glass into the appliance. Warning The Suction cup is provided to assist in moving the glass NEVER as the sole support of the glass.
-
Page 20: Product Operation
PRODUCT OPERATION PRODUCT OPERATION E-Smart Cloud App E-Smart Cloud App INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... - Page 21 PRODUCT OPERATION The appliance is operated by the E-Smart CLoud App, the main standby power switch to the E-Smart product is located to the right of the heater outlet, which is marked with a light bulb image, to activate the product, this switch must be switch to the “ON” position. The first time the E-Smart product is activated both the illumination and heater will function, to switch the heater “OFF”...
-
Page 22: E-Smart Cloud App Instructions
E-SMART CLOUD APP INSTRUCTIONS Wi-Fi Router Minimum Requirements • Compatible with IEEE 802.11n/g/b • WPA2 encryption • Radio frequency: 2.4GHz band • Wireless auto channel: auto search for wireless LAN radio channel free of interference • Support for the User Datagram Protocol (UDP) Smart Device Minimum Requirements •... - Page 23 CONTROL OVERVIEW To adjust the desired temperature of your fire ensure that the heater is selected on the To adjust the desired temperature of your fire ensure that the heater is selected on the Home Page in the previous step. Then press, hold, and rotate the temperature dial to set Home Page in the previous step.
- Page 24 PROGRAMMING THE TIMER Single press the clock icon on the Home Single press the clock icon on the Home Input your desired time in the Time box, Input your desired time in the Time box, Page to begin programming the Timer. Page to begin programming the Timer.
-
Page 25: Pairing With Amazon Alexa
Single press Search and type in Single press Search and type in Now on the Evonicfires Halo skill page Now on the Evonicfires Halo skill page evonicfires. Select the Evonicfires Halo evonicfires. Select the Evonicfires Halo... - Page 26 Enter the log in details that you Enter the log in details that you After a few moments your account will After a few moments your account will previously entered in the app set up previously entered in the app set up be linked, once this is done you can be linked, once this is done you can process, and single press Log In.
- Page 27 ALEXA COMMANDS When using Alexa to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Turning the appliance On and Off. “Alexa, turn fire on.” “Alexa, turn fire off.” Turning the heater On and Off. “Alexa, set fire heater to auto.”...
-
Page 28: Pairing With Google Home
PAIRING WITH GOOGLE HOME Once your fire is installed, and switched Once your fire is installed, and switched Single press Set up Device on the pop Single press Set up Device on the pop on, download and open the Google on, download and open the Google up list. - Page 29 Type in Evonic Fires, single press Type in Evonic Fires, single press Once in the evoflame log in page, enter Once in the evoflame log in page, enter search and then select the Evonic Fires search and then select the Evonic Fires the log in details that you previously log in details that you previously E-Smart icon.
- Page 30 GOOGLE HOME COMMANDS When using Google Home to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Please note that the Google Home app cannot control the heater in the appliance. Turning the appliance On and Off.
- Page 31 USING THE REMOTE Top Left - Turn your fire ON Top Right - Turn your and OFF feature lights ON and OFF Middle Left - Turn your Middle Right - Turn your heater ON heater OFF Bottom Left - This button Bottom Left - Adjust the has no functionality on brightness.
- Page 32 RETROFITTING THE REMOTE CONTROL In order to retro-fit your remote, please ensure you follow these steps BEFORE you attempt to use the remote control system. To begin the retro-fit of the remote To begin the retro-fit of the remote Once the fire has updated, select the Once the fire has updated, select the control, press the ‘update’...
-
Page 33: Product Specification
PRODUCT PRODUCT SPECIFICATION SPECIFICATION INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... -
Page 34: Gf3 Configurations
TYRELL SPECIFICATION DRAWINGS MODEL HEIGHT WIDTH DEPTH 31 1/8” 31 9/16” 11 13/16” TYRELL 790mm 802mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 1 bag of each Vermiculite 1 bag BOXED WEIGHT UNBOXED WEIGHT 50kg (110lbs) 39.55kg (87lbs) INSTRUCTION MANUAL ISS. - Page 35 MODEL HEIGHT WIDTH DEPTH 31 1/8” 31 9/16” 11 13/16” TYRELL 790mm 802mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 1 bag of each Vermiculite 1 bag BOXED WEIGHT UNBOXED WEIGHT 50kg (110lbs) 39.55kg (87lbs) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS.
- Page 36 MODEL HEIGHT WIDTH DEPTH 31 1/8” 31 9/16” 11 13/16” TYRELL 790mm 802mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 1 bag of each Vermiculite 1 bag BOXED WEIGHT UNBOXED WEIGHT 50kg (110lbs) 39.55kg (87lbs) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS.
-
Page 37: Gf2 Configurations
KIRUNA SPECIFICATION DRAWINGS MODEL HEIGHT WIDTH DEPTH 21 7/8” 39 9/16” 11 13/16” KIRUNA 556mm 1005mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 2 bags of each Vermiculite 4 bags BOXED WEIGHT UNBOXED WEIGHT 46kg (101lbs) 35.55kg (78lbs) INSTRUCTION MANUAL ISS. - Page 38 MODEL HEIGHT WIDTH DEPTH 21 7/8” 39 9/16” 11 13/16” KIRUNA 556mm 1005mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 2 bags of each Vermiculite 4 bags BOXED WEIGHT UNBOXED WEIGHT 46kg (101lbs) 35.55kg (78lbs) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS.
- Page 39 MODEL HEIGHT WIDTH DEPTH 21 7/8” 39 9/16” 11 13/16” KIRUNA 556mm 1005mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 2 bags of each Vermiculite 4 bags BOXED WEIGHT UNBOXED WEIGHT 46kg (101lbs) 35.55kg (78lbs) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS.
-
Page 40: Gf Configurations
LINNEA SPECIFICATION DRAWINGS MODEL HEIGHT WIDTH DEPTH 21 15/16” 59 3/16” 11 13/16” LINNEA 557mm 1503mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 3 bags of each Vermiculite 6 bags BOXED WEIGHT UNBOXED WEIGHT 64kg (141lbs) 53.55kg (119lbs) INSTRUCTION MANUAL ISS. - Page 41 MODEL HEIGHT WIDTH DEPTH 21 15/16” 59 3/16” 11 13/16” LINNEA 557mm 1503mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 3 bags of each Vermiculite 6 bags BOXED WEIGHT UNBOXED WEIGHT 64kg (141lbs) 53.55kg (119lbs) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS.
- Page 42 MODEL HEIGHT WIDTH DEPTH 21 15/16” 59 3/16” 11 13/16” LINNEA 557mm 1503mm 300mm FIRE MEDIA QUANTITY Glass - Amber & Clear 3 bags of each Vermiculite 6 bags BOXED WEIGHT UNBOXED WEIGHT 64kg (141lbs) 53.55kg (119lbs) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS.
-
Page 43: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... - Page 44 Troubleshooting Flow Chart Problem Possible Cause Solution 2” (50mm) 2” (50mm) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3...
- Page 45 Problem Possible Cause Solution INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3...
- Page 46 Problem Possible Cause Solution INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3...
- Page 47 Problem Possible Cause Solution 2” (50mm) INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3...
-
Page 48: Warranty
WARRANTY WARRANTY INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3... - Page 49 European Home Warranty European Home Warranty Electric Modern Family of Products European Home warrants all Electric Modern electric fireplaces against defects in materials and workmanship for a period of TWO (2) YEARS from the date of original retail purchase. If a defect exists, European Home will, at its option, either (1) repair the product at no charge, using new or refurbished re- placement parts or (2) exchange the product with one which is new or which has been manufactured from new or serviceable used parts and is at least...
- Page 50 European Home 30 Log Bridge Road, Building 300, Unit 303, Middleton, MA 01949 United States INSTRUCTION MANUAL ISS. 3 INSTRUCTION MANUAL ISS. 3...
