INSTRUCTIONS MUST BE KEPT AFTER INSTALLATION IN CASE
OF FUTURE MAINTENANCE
E-Smart Instruction Guide
Important Safety Information
Always read this manual first before attempting to install or use this
fireplace. For your safety, always comply with all warnings and safety
Instructions contained in this manual to prevent personal injury or property
damage.
Please Note: This product is for well insulated spaces or
occasional use.
SERIAL NUMBER LABEL
English
260991-Halo
1
Advertisement
Table of Contents
Related Manuals for Evonicfires AAREN
Summary of Contents for Evonicfires AAREN
- Page 1 INSTRUCTIONS MUST BE KEPT AFTER INSTALLATION IN CASE OF FUTURE MAINTENANCE E-Smart Instruction Guide Important Safety Information Always read this manual first before attempting to install or use this fireplace. For your safety, always comply with all warnings and safety Instructions contained in this manual to prevent personal injury or property damage.
-
Page 2: Table Of Contents
Warranty Information welcome to evonicfires evonicfires is an award-winning brand of CK Fires Ltd, situated just outside Stratford- upon-Avon, we manufacture a range of British built electric fires and are considered as one of the most technically advanced manufacturers in the world, with optional... -
Page 3: Electrical Safety
ELECTRICAL SAFETY: When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: ① Read all instructions before using this electric fireplace. ② This fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. - Page 4 ⑬ Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage to the heater. ⑭ To prevent a possible fire, do not block air intakes or exhaust in any manner.
-
Page 5: Important Instructions
IMPORTANT INSTRUCTIONS: Please read these instructions before installation or use and keep this booklet handy for future reference. All Evonic fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 - Restriction of Hazardous Substances EN 55014-1:2006 + A2:2011 Electromagnetic compatibility. - Page 6 Never use aerosols or steam cleaners near this product. Never route the electric cable near the heater outlet. Never route the electric cable under carpets or floor coverings. Never install this product close to curtains or combustible materials. Never Use the heater to dry clothes or other objects. Never remove the fireplace surrounding without isolating the electric supply.
-
Page 7: Installation Method
INSTALLATION METHOD: PLEASE NOTE: It is crucial to ensure that the product has a minimum internal clearance directly above and below the product of 100 mm, this is to ensure that the product can circulate the required airflow for the heater unit. Any faults as a result of ignoring the installation guidelines will invalidate the warranty. - Page 8 Lindstrom Installation Method: In order to successfully install this appliance, you must first make sure the plaster kit is properly assembled onto the fire . This is to ensure the main body of the fire can rest suitably onto a ledge and hold the weight of the fire.
-
Page 9: Glass Removal
Glass Removal:... - Page 10 Remove the glass by pulling the second retaining bar away from the body of the fire. Ensure that the glass is supported at all times. A suction cup has been provided to aid with this step. Please note: The suction cup is provided for support only, not to hold the full weight of the glass.
-
Page 11: Side Conversion Panels
Side Conversion Panels To complete this step, you must first remove front glass and side glass. ITEM. DESCRIPTION. QTY. SIDE GLASS 2 OFF FRONT GLASS 1 OFF PLASTER KIT (3 OFF LEFT SIDE, 3O FF RIGHT SIDE) 6 OFF MAIN HOUSING 1 OFF FRONT GLASS BOTTOM SUPPORT 1 OFF... - Page 12 STEP 1 - REMOVAL OF FRONT GLASS (ITEM 2) REMOVE THE 2 OFF FIXINGS (ITEM 7) THAT SECURE THE FRONT GLASS BOTTOM RETAINER (ITEM 6) TO THE FUEL BED (ITEM 8). LIFT OFF THE FRONT GLASS RETAINER (ITEM 7) AND USING THE GLASS SUCKERS SUPPLIED (NOT SHOWN) CAEFULLY REMOVE THE FRONT GLASS (ITEM 2).
- Page 13 STEP 2 - REMOVAL OF SIDE GLASS (ITEM 1) REMOVE THE 2 OFF SIDE GLASS TOP RETAINER BRACKETS (ITEM 9) BY TAKING OUT THE 4 OFF FIXINGS (ITEM 10) 2 OFF ON EACH BRACKET. CAREFULLY TILT THE SIDE GLASS INWARDS AT THE TOP AND LIFT IT AWAY FROM UNIT.
- Page 14 STEP 4—FITTING IN-FILL SIDES (ITEM 13 & 14) REMOVE IN-FILL SIDE FIXINGS (ITEM 12) PLACE THE IN-FILL SIDES OVER THE EXISTING SIDE PIECES USING THE IN-FILL SIDE FIXINGS (ITEM 12) TOGETHER WITH THE PLASTER KIT FIXINGS (ITEM 11) THAT WERE REMOVED IN THE PREVIOUS STEP SECURE THE LEFT AND RIGHT IN-FILL SIDES (ITEM 13 &...
-
Page 15: E-Smart App Template
E-Touch & App Interface: The Appliance is operated using the E-smart App Control. The App Control can be used on either OS or Android operating systems. To obtain the App please visit either the OS App Store Or Google Play and follow the on screen instructions. Home Screen shot taken from e-smart Screen shot taken from Apple App Store. -
Page 16: Product Operation
Product Operation: The appliance is operated by the e-smart App, the main standby power switch to the Halo product is located to the right of the heater outlet, which is marked with a light bulb image, to activate the product, this switch must be switch to the “ON”... - Page 17 Heater unit cut-out) (This is a safety feature, to safe guard against further damage to the product). If the airflow is restricted the heater will automatically turn off. This is can occur due to incorrect installation or obstruction. To reset the heater function: isolate from the mains power supply.
-
Page 18: Problem Solving Chart
Troubleshooting Flow Chart: Problem Possible Cause Solution Ribbons are statically connected to Spray some anti-static spray beneath glass. the tray. Check the correct aperture has been Installation airflow restricted. adhered to when installing— Recommended clearance is 100mm. Flames not working correctly Blower clogged. - Page 19 Problem Possible Cause Solution Fan unbalanced. Adjust fan to stop catching on the case. If problem persists replacement fan unit maybe required. Adjust fan to stop catching on the case Fan catching on housing. Noisy Heater Fan clogged. Fan requires cleaning out. If problem persists a replacement fan may be required.
- Page 20 Problem Possible Cause Solution Fan unbalanced. Adjust fan to stop catching on the case. If problem persists replacement fan unit maybe required. Adjust fan to stop catching on the case Fan catching on housing. Noisy Heater Fan clogged. Fan requires cleaning out. If problem persists a replacement fan may be required.
- Page 21 Problem Possible Cause Solution Timer has been accidentally set. Double check timer settings. Heater coming on randomly Thermostat faulty. Replace PCB. LED dropped down. LED needs to be re-stuck into place. LED streaking Log positioning. Change log positioning to hide any direct view of LED strip.
-
Page 22: Technical Specification
Technical Specification Specification including Tile Wings MODEL HEIGHT WIDTH DEPTH AAREN 687mm 845mm 360mm NESSA 520mm 1120mm 360mm BERGEN 615mm 1475mm 360mm TYRELL 790mm 1188mm 300mm KIRUNA 570mm 1418mm 300mm KALMAR 661mm 1474mm 375mm LINNEA 556mm 1914mm 300mm Specification without Tile Wings... -
Page 23: Warranty Information
This warranty is in addition to and does not affect the purchasers statutory rights of consumers. Registering product: o register a product please visit: www.evonicfires.co.uk and complete the fields required under the Register a Product Section. By registering your appliance, an extra... - Page 24 CK Fires Ltd / Evonic Fires 1 Evonic house, Clifford park, Clifford lane, Stratford-Upon-Avon, CV37 8HW Tel: +44 (0) 1789 263868 Fax: +44 (0) 1789 293080 Email: sales@evonicfires.co.uk — Follow us on Twitter @evonicfires...
