E-LECTRA / VOLANTE

INSTRUCTION MANUAL

E-lectra 1800

E-lectra 1500

E-lectra 1250

E-lectra 1030

E-lectra 800

E-lectra - S 1350

E-lectra - S 1500

EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1

Volante 1800

Volante 1500

Volante 1250

Volante 1030

Volante 800

ELECTRA ISS. 2

English

Need help?

Do you have a question about the VOLANTE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Evonicfires VOLANTE Series

Page 1 English English E-LECTRA / VOLANTE E-LECTRA / VOLANTE INSTRUCTION MANUAL INSTRUCTION MANUAL E-lectra 1800 Volante 1800 E-lectra 1500 Volante 1500 E-lectra 1250 Volante 1250 E-lectra 1030 Volante 1030 E-lectra 800 Volante 800 E-lectra - S 1350 E-lectra - S 1500 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
Page 2 CONTENTS EU Directives and UKCA Standards...............3 Important Information and Health & Safety............4 Components for Electra range................5 Built-In Installation....................6 Side glass installation...................15 Front glass installation..................17 Suite Installation....................19 Log Layouts......................24 Troubleshooting....................26 Warranty.......................28 The following materials and components should be disposed of in accordance with the below table.
Page 3 EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances.
Page 4 IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual.
Page 5 INSTALLATION INSTALLATION EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 2 ELECTRA ISS. 2...
Page 6 MODEL DIMENSIONS A - Width excl. plaster kit B - Width incl. plaster kit C - Opening height D - Depth excl. plaster kit E - Height For detailed MODEL specification drawings please scan E-lectra 1800 1753mm 1785mm 414mm 300mm 587mm the QR code Volante 1800...
Page 7 CONVERTING TO GF / GF2 / GF3 The appliance is shipped in the GF3 configuration, however all models can be converted to be GF or GF2 depending on your preference. GF Configuration Glass Fronted A single glass panel at the front of the appliance.
Page 8 INSTALLING THE SIDE PANELS / CONVERTING TO GF / GF2 Unscrew and remove the plaster kits from the side/s of the appliance. Screw in the side panel/s, on one or both sides. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
Page 9 INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • Consult a qualified professional to check the structure of the installation site. • These appliances have been designed to be installed into either a stud and plasterboard wall, or an existing chimney breast.
Page 10 CHECKS BEFORE INSTALLATION We recommend turning on the appliance before installation, connect the appliance to a power source using the provided electrical lead, and depress the right side of the rocker switch. Remove the electrical lead from the wall and continue with the installation. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
Page 11 INSTALLATION STEPS Remove the bottom transit brackets, and side brace bars. Then screw on the top mounted brackets, and the IEC Clip on the back right. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS.
Page 12 Screw the two top mounted brackets to the wall. You can now construct your stud wall/s around the appliance in the design of your choosing. When constructing the studwork, remember that the vents on the underside of the appliance need a minimum of 50mm clearance beneath them.
Page 13 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Alternatively, the optional chrome side panels can be attached to the case with the magnets as shown below. Ensure that the magnets are positioned with the short side touching the case.
Page 14 INSTALLING THE SIDE INSTALLING THE SIDE GLASS PANELS GLASS PANELS EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 2 ELECTRA ISS. 2...
Page 15 INSTALLING THE SIDE GLASS PANELS Unscrew and remove the top and bottom glass retainer panels. Slide in the side glass pieces. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 2 ELECTRA ISS.
Page 16 INSTALLING THE FRONT INSTALLING THE FRONT GLASS PANEL GLASS PANEL Please Note: The glass suction pad comes with models Volante 1800 and e-lectra 1800. On all other models, the glass suction pad is an optional extra. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
Page 17 INSTALLING THE FRONT GLASS PANEL If using a glass sucker, apply the Suction Lifter to the glass and position the bottom edge of the glass first, then pivot the glass into the appliance. If not using a glass sucker, carefully hold the glass on either end and follow the same process. 2 people may be required for this to ensure the glass is carefully supported at all times.
Page 18 INSTALLATION INSTALLATION E-LECTRA S-1350 E-LECTRA S-1500 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 2 ELECTRA ISS. 2...
Page 19 INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • The appliance must never be installed in front of an electrical socket. • The appliance must not be installed anywhere that it may come into contact with water, i.e.
Page 20 TOOLS REQUIRED • Tape Measure • Drill Bit • Pencil • Wall Plugs (Masonry type supplied) • Spirit Level • Wall Screws (Masonry type supplied) • Screwdriver • Stud Detector (For plasterboard • PZ2 Screw Bit installations only) • Wall Anchors (For plasterboard installations only.
Page 21 Determine the finished height and position that you want the appliance to be located. Then secure the wall bracket to the wall in the position you need using the wall plugs and screws provided. If you’re not securing the appliance to a masonry wall you will need to use the appropriate fixings.
Page 22 You can now hang the appliance on the wall by slotting the tabs of the wall bracket into the slots on the back of the appliance. Connect the appliance to the mains power supply and it is ready to use. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
Page 23 LOG LAYOUTS LOG LAYOUTS EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 2 ELECTRA ISS. 2...
Page 24 LOG LAYOUTS When you have your appliance installed you can set up your log set/s. Lay the coconut husk on the fuel bed first, then continue with laying out your logs. There is no right or wrong way to arrange your logs, the following images are an example of how you could lay them out.
Page 25 TROUBLESHOOTING TROUBLESHOOTING Heater Access & Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 24 of this instruction manual for the new method.
Page 26 To receive your Extended Warranty your Evonic Fires product must have been purchased from an authorised stockist within our Retailer Network and your warranty registered with Evonic Fires through the online form - evonicfires.co.uk/register-your-product. The commencement date for the warranty period is the date of purchase.
Page 27 WARRANTY EXCLUSIONS AND LIMITATIONS Repaired or replaced products are covered only for the remainder of the original warranty period. In the event of a claim being made, this must be reported to your retailer or CK Fires Ltd within 14 days of the fault occurring/being noticed.
Page 28 CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk www.evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
