BUILT-INS

Evoflame & E-Smart

INSTRUCTION MANUAL

E500

E600

E630

E640

E700

E710

E730

E800

E810

EVONIC - 104 INSTRUCTION MANUAL ISS. 6

E900

E1000

E1030

E1250

E1500

E1560

E1800

E2400

English

Avesta

Kallan

Karlstad

Kiruna

Linnea

Motala

Thoren

Tyrell

Valter

Table of Contents

Need help?

Do you have a question about the Evoflame E500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Evonicfires Evoflame E500

Page 1 English English BUILT-INS BUILT-INS Evoflame & E-Smart Evoflame & E-Smart INSTRUCTION MANUAL INSTRUCTION MANUAL E500 E500 E900 E900 Avesta Avesta E600 E600 E1000 E1000 Kallan Kallan E630 E630 E1030 E1030 Karlstad Karlstad E640 E640 E1250 E1250 Kiruna Kiruna E700 E700 E1500 E1500 Linnea...
Page 2: Table Of Contents
CONTENTS EU Directives and UKCA Standards..............3 Important Information and Health & Safety............4 Components for Evoflame..................5 Components for E-Smart..................6 App Instructions....................7 E-Smart Cloud App Instructions (Evoflame Models)........8 E-Smart Cloud App Instructions (E-Smart Models)........10 Pairing with Amazon Alexa..............13 Pairing with Google Home..............16 Installation......................
Page 3: Eu Directives And Ukca Standards
EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances.
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual.
Page 5: Components For Evoflame
EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 6: Components For E-Smart
EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 7: App Instructions
APP INSTRUCTIONS APP INSTRUCTIONS EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 8: E-Smart Cloud App Instructions (Evoflame Models)
E-SMART APP INSTRUCTIONS (EVOFLAME MODELS) The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet devices, and is available on both the Apple App Store and Google Play Store.
Page 9 CONTROL OVERVIEW To adjust the desired temperature of your fire ensure that the heater is selected on the To adjust the desired temperature of your fire ensure that the heater is selected on the Home Page in the previous step. Then press, hold, and rotate the temperature dial to set Home Page in the previous step.
Page 10: E-Smart Cloud App Instructions (E-Smart Models)
E-SMART CLOUD APP INSTRUCTIONS (E-SMART MODELS) The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet devices, and is available on both the Apple App Store and Google Play Store.
Page 11 CONTROL OVERVIEW To adjust the desired temperature of your fire ensure that the heater is selected on the To adjust the desired temperature of your fire ensure that the heater is selected on the Home Page in the previous step. Then press, hold, and rotate the temperature dial to set Home Page in the previous step.
Page 12 PROGRAMMING THE TIMER Single press the clock icon on the Home Single press the clock icon on the Home Input your desired time in the Time box, Input your desired time in the Time box, Page to begin programming the Timer. Page to begin programming the Timer.
Page 13: Pairing With Amazon Alexa
Single press Search and type in Single press Search and type in Now on the Evonicfires Halo skill page Now on the Evonicfires Halo skill page evonicfires. Select the Evonicfires Halo evonicfires. Select the Evonicfires Halo...
Page 14 Enter the log in details that you Enter the log in details that you After a few moments your account will After a few moments your account will previously entered in the app set up previously entered in the app set up be linked, once this is done you can be linked, once this is done you can process, and single press Log In.
Page 15 ALEXA COMMANDS When using Alexa to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Turning the appliance On and Off. “Alexa, turn fire on.” “Alexa, turn fire off.” Turning the heater On and Off. “Alexa, set fire heater to auto.”...
Page 16: Pairing With Google Home
PAIRING WITH GOOGLE HOME Once your fire is installed, and switched Once your fire is installed, and switched Single press Set up Device on the pop Single press Set up Device on the pop on, download and open the Google on, download and open the Google up list.
Page 17 Type in Evonic Fires, single press Type in Evonic Fires, single press Once in the evoflame log in page, enter Once in the evoflame log in page, enter search and then select the Evonic Fires search and then select the Evonic Fires the log in details that you previously log in details that you previously E-Smart icon.
Page 18 GOOGLE HOME COMMANDS When using Google Home to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Please note that the Google Home app cannot control the heater in the appliance. Turning the appliance On and Off.
Page 19: Installation
INSTALLATION INSTALLATION Evoflame & E-Smart Evoflame & E-Smart EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 20: Model Dimensions
MODEL DIMENSIONS The model shown in these drawings is an E1030, however the same processes apply to all Evoflame and E-Smart models. Scan the QR code for more detailed specification drawings. EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 21 MODEL DIMENSIONS Model Width Height Depth With With No glass Overall Overall glass optional Opening or side unit unit sides side panels panels E500 524mm 540mm 609mm 397mm 316mm E600 670mm 686mm 638mm 455mm 196mm E630 670mm 688mm 640mm 455mm 316mm E640 508mm...
Page 22: Installation Process
INSTALLATION PROCESS Evoflame or E-Smart Model Evoflame or E-Smart Model (GF2) (GF2) (GF) (GF) (GF3) (GF3) Front & Front & Open Open Glass Glass Front & Front & 1 Glass Side 1 Glass Side Fronted Fronted Fronted Fronted 2 Glass Sides 2 Glass Sides Fit 2 Side Panels Fit 2 Side Panels...
Page 23: Converting To Gf / Gf2 / Gf3
CONVERTING TO GF / GF2 / GF3 The appliance is shipped in the GF3 configuration, however most models can be converted to be GF or GF2 depending on your preference. GF Configuration Glass Fronted A single glass panel at the front of the appliance.
Page 24: Installing The Side Panels / Converting To Gf / Gf2
INSTALLING THE SIDE PANELS / CONVERTING TO GF / GF2 Unscrew and remove the plaster kits from the side/s of the appliance. Screw in the side panel/s, on one or both sides. EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 25: Requirements And Checks
INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • Consult a qualified professional to check the structure of the installation site. • These appliances have been designed to be installed into either a stud and plasterboard wall, or an existing chimney breast.
Page 26 CHECKS BEFORE INSTALLATION We recommend turning on the appliance before installation, connect the appliance to a power source using the provided electrical lead, and depress the right side of the rocker switch. Remove the electrical lead from the wall and continue with the installation. EVONIC - 104 INSTRUCTION MANUAL ISS.
Page 27: Installation
TOOLS REQUIRED • Tape Measure • Rear Wall Screws (Masonry type supplied) • Pencil • Top Mounted Bracket Screws x 6 (supplied) • Spirit Level • Top Mounted Bracket Wall Screws x 8 • Screwdriver (supplied) • PZ2 Screw Bit •...
Page 28 Determine the finished height and position that you want the appliance to be located. Then secure the wall bracket to the wall in the position you need using the wall plugs and screws provided. If you’re not securing the appliance to a masonry wall you will need to use the appropriate fixings.
Page 29 Screw the two top mounted brackets to the wall. You can now construct your stud wall/s around the appliance in the design of your choosing. When constructing the studwork, remember that the vents on the underside of the appliance need a minimum of 50mm clearance beneath them.
Page 30 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Alternatively, the chrome side panels can be attached to the case with the magnets as shown below. Ensure that the magnets are positioned with the short side touching the case. EVONIC - 104 INSTRUCTION MANUAL ISS.
Page 31: Log Layouts
LOG LAYOUTS LOG LAYOUTS Evoflame & E-Smart Evoflame & E-Smart EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 32 LOG LAYOUTS When you have your appliance installed you can set up your log set/s. If your model comes with Chippings, Glass Stones and/or Vermiculite lay this on the fuel bed first, then continue with laying out your logs. There is no right or wrong way to arrange your logs, the following images are an example of how you could lay them out.
Page 33 4 x Large Woodland / Silver Birch E2400 1 x Medium Split Woodland / Silver Birch Tyrell 1 x Small Split Woodland / Silver Birch Kiruna / Motala 2 x Small Split Woodland / Silver Birch Avesta 1 x Large Split Woodland / Silver Birch Linnea 1 x Small Split Woodland / Silver Birch &...
Page 34: Installing The Side Glass
INSTALLING THE SIDE INSTALLING THE SIDE GLASS PANELS GLASS PANELS EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 35 INSTALLING THE SIDE GLASS PANELS Unscrew and remove the top and bottom glass retainer panels. Slide in the side glass pieces. EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 36: Installing The Front Glass
INSTALLING THE FRONT INSTALLING THE FRONT GLASS PANEL GLASS PANEL EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 37 INSTALLING THE FRONT GLASS PANEL Apply the Suction Lifter to the glass and position the bottom edge of the glass first, then pivot the glass into the appliance. Then replace the top and bottom glass retainers. EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS.
Page 38: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Evoflame & E-Smart Evoflame & E-Smart EVONIC - 104 INSTRUCTION MANUAL ISS. 6 EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
Page 39 Evoflame Only LED Strip Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 25 of this instruction manual for the new method.
Page 40 CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires EVONIC - 104 INSTRUCTION MANUAL ISS. 6...
