- Page 1 English English ELECTRA ELECTRA INSTRUCTION MANUAL INSTRUCTION MANUAL ELECTRA 1500 ELECTRA 1250 ELECTRA - S 1350 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS. 1...
-
Page 2: Table Of Contents
CONTENTS EU Directives and UKCA Standards...............3 Important Information and Health & Safety............4 Components for Electra range................5 Built-In Installation....................6 Side glass installation...................15 Front glass installation..................17 Suite Installation....................19 Log Layouts......................24 Troubleshooting....................26 Warranty.......................28 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. -
Page 3: Eu Directives And Ukca Standards
EU DIRECTIVES All Evonic Fires products meet the requirements of the EC Directives. All Evonic Fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances. -
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual. -
Page 5: Components For Electra Range
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS. 1... -
Page 6: Built-In Installation
INSTALLATION INSTALLATION ELECTRA 1500 ELECTRA 1250 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS. 1... - Page 7 MODEL DIMENSIONS The model shown in these drawings is an Electra 1250, however the same processes apply to all Evoflame and E-Smart models. Scan the QR code for more detailed specification drawings. A - Width excl. plaster kit B - Width incl. plaster kit C - Opening height D - Depth excl.
- Page 8 CONVERTING TO GF / GF2 / GF3 The appliance is shipped in the GF3 configuration, however most models can be converted to be GF or GF2 depending on your preference. This process only applies to Electra 1500 and Electra 1250. GF Configuration Glass Fronted A single glass panel at the front of the...
- Page 9 INSTALLING THE SIDE PANELS / CONVERTING TO GF / GF2 Unscrew and remove the plaster kits from the side/s of the appliance. Screw in the side panel/s, on one or both sides. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
- Page 10 INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • Consult a qualified professional to check the structure of the installation site. • These appliances have been designed to be installed into either a stud and plasterboard wall, or an existing chimney breast.
- Page 11 CHECKS BEFORE INSTALLATION We recommend turning on the appliance before installation, connect the appliance to a power source using the provided electrical lead, and depress the right side of the rocker switch. Remove the electrical lead from the wall and continue with the installation. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
- Page 12 INSTALLATION STEPS Remove the bottom transit brackets, and side brace bars. Then screw on the top mounted brackets, and the IEC Clip on the back right. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS.
- Page 13 Screw the two top mounted brackets to the wall. You can now construct your stud wall/s around the appliance in the design of your choosing. When constructing the studwork, remember that the vents on the underside of the appliance need a minimum of 50mm clearance beneath them.
- Page 14 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Alternatively, the optional chrome side panels can be attached to the case with the magnets as shown below. Ensure that the magnets are positioned with the short side touching the case.
-
Page 15: Side Glass Installation
INSTALLING THE SIDE INSTALLING THE SIDE GLASS PANELS GLASS PANELS EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS. 1... - Page 16 INSTALLING THE SIDE GLASS PANELS Unscrew and remove the top and bottom glass retainer panels. Slide in the side glass pieces. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS.
-
Page 17: Front Glass Installation
INSTALLING THE FRONT INSTALLING THE FRONT GLASS PANEL GLASS PANEL Please Note: The glass suction pad is an optional extra on both Electra built-in models. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. - Page 18 INSTALLING THE FRONT GLASS PANEL If using a glass sucker, apply the Suction Lifter to the glass and position the bottom edge of the glass first, then pivot the glass into the appliance. If not using a glass sucker, carefully hold the glass on either end and follow the same process. 2 people may be required for this to ensure the glass is carefully supported at all times.
-
Page 19: Suite Installation
INSTALLATION INSTALLATION ELECTRA S-1350 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS. 1... - Page 20 INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • The appliance must never be installed in front of an electrical socket. • The appliance must not be installed anywhere that it may come into contact with water, i.e.
- Page 21 TOOLS REQUIRED • Tape Measure • Drill Bit • Pencil • Wall Plugs (Masonry type supplied) • Spirit Level • Wall Screws (Masonry type supplied) • Screwdriver • Stud Detector (For plasterboard • PZ2 Screw Bit installations only) • Wall Anchors (For plasterboard installations only.
- Page 22 Determine the finished height and position that you want the appliance to be located. Then secure the wall bracket to the wall in the position you need using the wall plugs and screws provided. If you’re not securing the appliance to a masonry wall you will need to use the appropriate fixings.
- Page 23 You can now hang the appliance on the wall by slotting the tabs of the wall bracket into the slots on the back of the appliance. Connect the appliance to the mains power supply and it is ready to use. EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
-
Page 24: Log Layouts
LOG LAYOUTS LOG LAYOUTS EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS. 1... - Page 25 LOG LAYOUTS When you have your appliance installed you can set up your log set/s. Lay the coconut husk on the fuel bed first, then continue with laying out your logs. There is no right or wrong way to arrange your logs, the following images are an example of how you could lay them out.
-
Page 26: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 ELECTRA ISS. 1 ELECTRA ISS. 1... - Page 27 Heater Access & Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 24 of this instruction manual for the new method.
-
Page 28: Warranty
To receive your Extended Warranty your Evonic Fires product must have been purchased from an authorised stockist within our Retailer Network and your warranty registered with Evonic Fires through the online form - evonicfires.co.uk/register-your-product. The commencement date for the warranty period is the date of purchase. - Page 29 WARRANTY EXCLUSIONS AND LIMITATIONS Repaired or replaced products are covered only for the remainder of the original warranty period. In the event of a claim being made, this must be reported to your retailer or CK Fires Ltd within 14 days of the fault occurring/being noticed.
- Page 30 CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk www.evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS.
