PowerView® Roller Blind 230VAC
Programming with Remote control
The PowerView® M40T tubular motor is suited to be used with EOS® 500 Roller Blinds from Hunter Douglas.
1. Delivery condition
As standard, no remote control or hub is connected to the motor. No limits are set. Motor is default set to
motor type.
ller blind
IMPORTANT!
Factory fresh motors do not have default limits set. Limits must be set to enable normal operation. If
operated without limits, the shade could be damaged by rolling over the top or wrapping backwards on
the roller.
1.2. Network reset
This procedure will erase all network data stored in the motor, including Network ID and Group assignments.
It will not clear the end limits. Completing a Network reset will prevent a PowerView® remote or App from
operating the window covering until it is reprogrammed.
Page 1 of 18
ro
version: 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerView M40T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HunterDouglas PowerView M40T

Summary of Contents for HunterDouglas PowerView M40T

  • Page 1 PowerView® Roller Blind 230VAC Programming with Remote control The PowerView® M40T tubular motor is suited to be used with EOS® 500 Roller Blinds from Hunter Douglas. 1. Delivery condition As standard, no remote control or hub is connected to the motor. No limits are set. Motor is default set to motor type.
  • Page 2 1.2.1 Press and hold the manual control button the motor for 12 seconds The blind will jog 1x at 6 seconds and a second time at 12 seconds 1.2.2 Release the after the manual control button second jog. The Network ID and Group assignments have been cleared.
  • Page 3 Procedure Locate the on your manual control button blind. Press and hold the  button for 4 seconds. stop Keep pressing until the remote lights start blinking Press the  button. group1 IMPORTANT Watch out to perform steps 2.4 and 2.5 within 3 seconds! Page 3 of 18 version: 1.0...
  • Page 4 Press and hold the manual control button Press the  button. open The blind will jog 2x Release the manual control button The blind will jog 2x to indicate it has joined the group Press and hold the  button for 4 seconds. stop The remote will exit programming mode automatically after 20 seconds.

  • Page 5: Reversing Motor Direction

    3. Reversing motor direction IMPORTANT Reversing motor direction is only possible with a fresh out of the box motor (no limits set) or when the end limits are reset. Before any limits are programmed, the motor direction has to be checked and reversed if needed.
  • Page 6 3.1.3 Press and release the  button. stop Make sure  on the remote is no group selected. The blind will jog 2x to indicate it has reversed motor direction 3.1.4 Release the manual control button Note If end limits were already set, the motor will not jog, indicating the motor direction did not change. Note Verify that all GROUP lights are turned off on the remote, clear both limits, and try again.
  • Page 7 3.2.1 Press the  button to check motor arrow down direction. 3.2.2.A If the blind moves upwards, repeat steps 3.2.2.B If the blind moves downwards, continue with 3.1.1 --> 3.1.3 step 4.1.4 Motor direction NOT OK! Motor direction OK! 4. Setting end limits It doesn’t matter if you start with setting the open or the close limit first.
  • Page 8 4.1. Open limit (top) 4.1.1 Use the manual button on the motor to move the blind to the desired top position Each "press and release" of the button will toggle between Up, Stop and Down. 4.1.2 Use the  ,  and ...
  • Page 9 IMPORTANT Watch out to perform steps 4.1.6 and 4.1.7 within 3 seconds! 4.1.4 Press and hold the manual control button 4.1.5 Press the  button. open The blind will jog 2x to acknowledge the limit is set 4.1.6 Release the manual control button Page 9 of 18 version: 1.0...
  • Page 10 4.1.7 Press and hold the  button for 6 seconds. stop The remote will exit programming mode automatically after 20 seconds. Keep pressing until the remote lights stop blinking 4.1.8 The top limit is set! Note To re-position the top limit of the blind, clear the top limit and repeat step 4.1 Open limit (top) 4.2.
  • Page 11 4.2.2 Use the  ,  and  buttons open stop close to fine tune the blind to the desired position. 4.2.3 Press and hold the  button for 6 seconds. stop DO NOT select a group on the remote! Keep pressing until the remote lights start blinking IMPORTANT...
  • Page 12 4.2.5 Press the  button. close The blind will jog 2x to acknowledge the bottom limit is 4.2.6 Release the manual control button 4.2.7 Press and hold the  button for 6 seconds. stop The remote will exit programming mode automatically after 20 seconds.
  • Page 13 Note To re-position the bottom limit of the blind, clear the bottom limit and repeat step 4.2. Close limit (bottom) 5. Clearing end limits 5.1 Clear top limit 5.1.1 Deselect all Group number on the remote IMPORTANT Watch out to perform steps 6.1.2 and 6.1.3 within 3 seconds! 5.1.2 Press and hold the manual control button...
  • Page 14 5.1.3 Press the  button. open The blind will jog 2x to indicate the top limit is cleared 5.1.4 Release the manual control button 5.2 Clear bottom limit 5.2.1 Deselect all Group number on the remote IMPORTANT Watch out to perform steps 6.2.2 and 6.2.3 within 3 seconds! Page 14 of 18 version: 1.0...
  • Page 15 5.2.2 Press and hold the manual control button 5.2.3 Press the  button. close The blind will jog 2x to indicate the bottom limit is cleared 5.2.4 Release the manual control button 6. Set a favourite position (optional) Note After the top and bottom limit are set, the motor will hav one FAVOURITE position, which is set at 50% open by default.
  • Page 16 6.1 Set favourite position 6.1.1 Use the  ,  ,  ,  open stop close arrow and the  buttons to move the down arrow up blind to the desired favourite position. 6.1.2 Press and hold the  button for 6 seconds.

  • Page 17: Reset To Factory Default

    6.1.4 Press the  button. heart The blind will jog 2x to indicate the favourite position is set 6.1.5 Release the manual control button 7 Reset to factory default The factory default reset erases all information stored in a shade motor. The motor is returned to its factory default settings of no network programming, no limits, and the motor direction is reset.
  • Page 18 Release the after the manual control button third jog. The Network ID, Group assignments and end Limits have been cleared. Page 18 of 18 version: 1.0...
