SECURE THE SEAT TO THE
3
SEAT POST
1. Lay the seat (10) on the floor, underside up.
2. Use the multi-tool (40) to remove the three flat washers
nuts (12) from the seat (10).
3. Lay the seat on the floor, underside up.
4. Slide the seat post (13) onto the three integrated bolts on the
underside of the seat.
5. Place a flat washer (11) onto each bolt.
6. Screw a nut (12) onto each bolt.
7. Use the multi-tool to fully tighten the three nuts.
TOOLS & HARDWARE
(40)
(11) x3
(12) x3
12 VeloCycle User Manual Lifepro
(11) and three
13
12
11
10
ATTACH THE BACKREST
4
TO THE SEAT AND BACKREST FRAME
1. Remove four bolts (18) and four flat washers
seat and backrest frame (17).
2. Place a flat washer (19) onto each bolt (18).
3. Insert each bolt/washer combination through the BACK of the four bolt
holes in the seat and backrest frame
backside of the backrest (16).
4. Use the 4mm hex key (41) to tighten each bolt.
TOOLS & HARDWARE
(41)
(4mm)
(18) x4
(19) x2
(19) from the rear of the
(17) and into the bolt holes in the
16
17
19
18
