Lifepro READY, SET, PRO User Manual page 6

30-MINUTE ASSEMBLY GUIDE
INSERT THE LOCKING PIN
1
TO SECURE THE BIKE FRAME
CAUTION: Use caution when inserting the locking pin, as the bike frame
could accidentally fall over. You may find it easier to lay the bike frame on
its side for this step.
1. Locate the locking pin (3) in the tool/accessory bag.
2. Open the bike frame (1).
3. Align outer hole in the locking pin bracket
post insert (14).
4. Insert the locking pin through the hole in the
bracket and through the seat post insert.
NOTE: The second hole in the locking pin
bracket is used to lock the bike in its
folded configuration for storage and
transportation. See
FOLDING THE
on page 28 for
VELOCYCLE
instructions.
TOOLS & HARDWARE
(3) x1
10 VeloCycle User Manual Lifepro
(4) with the hole in the seat
1
14
3
4
ATTACH THE FRONT AND
2
REAR STABILIZERS
CAUTION: Use caution when attaching the stabilizers as the bike frame
could accidentally fall over. You may find it easier to lay the bike frame on
its side for this step.
1. Locate the multi-tool (40) in the tool/accessory bag.
2. Remove the two curved washers
front stabilizer (6).
3. Insert the two bolts integrated in the front stabilizer through the bolt
holes in the curved metal attachment point on the front of the bike. Make
sure the wheels on the front stabilizer are facing out.
4. Place a curved washer (8) onto each integrated bolt.
5. Screw a cap nut (9) onto the end of each bolt.
6. Repeat steps 3–5 to attach the rear stabilizer (7).
7. Use the multi-tool to fully tighten all four cap nuts.
8. Ensure the bike frame is stable when upright. You may need to rotate
the octagonal rubber end caps on either end of the rear stabilizer to
ensure complete stability.
Front of
Bike
9
8
7
(8) and two cap nuts (9) from the
TOOLS & HARDWARE
1
(40)
(8) x4
(9) x4
9
8
6
Endurance Training Collection 11 Endurance Training Collection 11
