MY
Coway Water Purifier
User's Manual
P-6320R
This product cannot be used if the voltage is different from that
mentioned in the rating plate.
For your safety and proper use of the product, please read this
User's Manual before use.
This paper can be recycled.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P-6320R and is the answer not in the manual?

Questions and answers

Related Manuals for Coway P-6320R

Summary of Contents for Coway P-6320R

  • Page 1 Coway Water Purifier User's Manual P-6320R This product cannot be used if the voltage is different from that mentioned in the rating plate. For your safety and proper use of the product, please read this User’s Manual before use. This paper can be recycled.
  • Page 2 FEATURES Clean and tasty water Coway's outstanding Intensive RO Filter System provides clean and better- tasting water. Space saving slim design Slim design makes it a perfect fit for kitchen counters. Automatic dispensing mode You can choose the preferred water volume with just one touch.

  • Page 3: Table Of Contents

    DEAR CUSTOMERS COWAY Coway Water Purifier Thank you for using Please read this User's Manual carefully for correct use and maintenance of the product. You can refer to the User's Manual to troubleshoot for product issues while using it. Please keep this User's Manual in a safe place.

  • Page 4: Safety Information

    SAFETY INFORMATION Please follow all the instructions for your safety! These instructions are to keep you safe and to prevent property damage. Please use the product correctly after carefully reading the precautions. Death or serious injury may Severe injury or property Minor bodily or property occur if the instruction is not damage may occur if the...

  • Page 5: Installation

    Product information Do not connect multiple products to one power outlet. Use a separate socket for the product. There is a risk of electric shock or fire. If you don’t use it for a long time, then close the tap water supply valve and disconnect the power adapter.

  • Page 6: During Use

    SAFETY INFORMATION Please follow all the instructions for your safety! These instructions are to keep you safe and to prevent property damage. Please use the product correctly after carefully reading the precautions. Death or serious injury may Severe injury or property Minor bodily or property occur if the instruction is not damage may occur if the...

  • Page 7: Others

    Product information Others Do not directly spray water on product for cleaning or use benzene or thinner to wipe the product. There is a risk of electric shock or fire. Do not arbitrarily open, repair, or remodel the product. There is risk of electrocution and product damage. Do not use the filtered water for replacing water in fish tanks and aquariums.

  • Page 8: Part Names

    PART NAMES Front/Rear Water volume button Dispensing button Locking lever (for Faucet filter replacement) Power adapter connection port Reject water outlet (OUT) Feed water inlet (IN) Accessories User's Manual Power Adapter Antibacterial Filter Twin tubing (1 ea) Elbow fitting (2 ea) Drain hose...

  • Page 9: Water Purification Process

    If you use a non-authentic filter or use an authentic filter too long, then the overall performance of the water purifier may decrease. 5-Step Water Purification System (P-6320R) 1st filter: Plus Neo-Sense filter - Step 1: It removes particulate materials, sediments, rust, dirt, sand and all other similar impurities.
  • Page 10 CHECK BEFORE USE Please check before use! This product is for 24 V Make sure to connect the power adapter to a 24 V outlet. It requires a power supply to operate. Connecting Power Adapter Before using the water purifier, connect the power adapter to the port on the bottom rear of the product.
  • Page 11 • Get a filter replacement and maintenance check in accordance with the intervals designated filter replacement time for each filter. • Our water purifier is managed by Coway Cody and service managers. Management Management • When non-specialists replace or clean internal parts of our product, there may be authority a risk of water leakage, so please ask our Cody and service managers for service.
  • Page 12 HOW TO INSTALL Installation guide Tap Water Supply Valve Only for 24 V Feed water inlet hose (orange) Reject water outlet hose (blue) Power adapter connection port Connect the feed water inlet hose (orange color) to the feed water inlet part (IN) Connect the residential water (blue color) to the reject water outlet part (OUT) Feed water inlet (IN)
  • Page 13 How to use Caution! Installation LocationⅠ Avoid installing the water purifier in an area with uneven surface, extreme humidity, extreme light exposure, extreme dust exposure, and water exposure, etc. Installation LocationⅡ Keep the radiator grill at the rear of the product at least 5 cm away from the wall and make sure that the installation floor is firm.
  • Page 14 BUTTONS AND INDICATORS Buttons / Indicators Water volume indicator/ Water volume button Dispensing indicator/ Dispensing button Water volume indicator/ Dispensing indicator/ Water volume button Dispensing button It indicates the selected water volume. The indicator turns on when dispensing function is operated. Press the button to choose the desired water volume to dispense.
  • Page 15 HOW TO GET THE DESIRED WATER How to use How to get ambient water Press the dispensing button, once you have the desired amount, press the button again to stop. - To use automatic dispensing mode Touch the water volume icon to select the desired water volume. Each time you touch the icon, the water volume changes in the order of half cup →...

  • Page 16: How To Clean

    HOW TO CLEAN How to clean the water tank 1. After closing the tap water supply valve, connect the drain hose to the faucet. Place an empty bucket (more than 5L) under the faucet and put the drain hose in a bucket. Press and hold the dispensing button for 2 seconds or longer to conduct continuous dispensing, and unplug the power adapter after finishing the drain.
  • Page 17 Maintenance 5. Rinse the water tank with the purified water drained from this appliance. Then plug in the power adapter to drain the remaining water completely. (After completely draining water, use it after emptying with newly dispensed water at least once.) 6.

  • Page 18: How To Clean The Main Body

    HOW TO CLEAN How to clean the main body Use a dry and soft cloth to wipe it off. If the area needs more cleaning, wet a cloth slightly and wipe it off. (Do not use an abrasive.) - Do not spray water directly to the product to clean it. Tips - Do not use thinner, benzene or agent containing abrasives or rough cloths to clean it.
  • Page 19 Maintenance How to clean faucet 1. Turn the faucet clockwise to separate it. 2. Wash the separated faucet in the running water. 3. Clean the faucet with a soft, dry cloth. 4. When cleaning is complete, turn the faucet counterclockwise until it clicks to assemble it again.

  • Page 20: Filter Replacement

    If you do not replace the filters regularly, the quality of water from the product may decrease. The expected filter replacement cycle can vary depending on the feed water characteristics or the amount of purified water used. P-6320R Filter name Expected Replacement Cycle...

  • Page 21: How To Replace Filter

    HOW TO REPLACE FILTER Maintenance Replace the Filter! 1. Close the tap water supply valve, drain the water inside the water purifier completely, and unplug the power adapter. 2. Pull the filter replacement lever on the right rear side of the product and slide the side cover backward to separate it.
  • Page 22 TROUBLESHOOTING The water purifier may operate abnormally due to minor causes not because of the product malfunction but because of the fact that the user is not familiar with the product use. In such a case, problems can be solved easily even without the help from the Service Center by checking the following items.
  • Page 23 Call center : 213-386-3033 Tel. : 041-850-7879 THAILAND MALAYSIA Add : Coway (Thailand) Co., Ltd. Add: Coway (Malaysia) Sdn. Bhd. 75/104-106 Ocean Tower 2 38th Fl, Soi Sukhumvit 19 Level 20, Ilham Tower, No. 8, Jalan Binjai, 50450 Kuala (Wattana), Sukhumvit Road, Klongtoey Nua, Wattana, Lumpur.
  • Page 24 WATER FLOW DIAGRAM P-6320R Reject water control valve Water purification Dispensing valve tank Drainage FEED valve valve Dispensing Decompression Valve Water source input Injection flow path Booster pump...
  • Page 25 MEMO Other...
  • Page 26 MEMO...
  • Page 27 MEMO Other...
  • Page 28 9238334 www.coway.co.kr...
