004
Feed Water
Feed Valve
Disposed Water
for Flushing
Disposed Water
Controlling Valve
Voltage rating that matches it on the rating plate.
Working Pressure
Working Temperature
Production Rate
Without any prior notice, all or parts of the product are
subject to change for the purpose of improving the
performance of the product.
Efficiency rating means the percentage of the influent water
to the system that is available to the user as reverse
osmosis treated water under operating conditions that
approximate typical daily usage.
Recovery rating means the percentage of the influent water
to the membrane portion of the system that is available to
the user as reverse osmosis treated water when the system
is operated without a storage tank or when the storage tank
is by passed.
1005629
Straight Fitting
(1/4"+3/8")
Filtered Water
Stem Elbow
HPS
Check Fitting
LPS
Booster
Pump
HPS_A
Feed Valve
for Feed Water
R/O
0.07-0.83MPa(10-120psi)
41-95℉ (5-35℃)
700gal/day
244(W)×405(D)×450(H)mm
<9.6(W)×16(D)×17.7(H)inch>
12kg(26.5lb)
Advertisement
Table of Contents
Related Manuals for Coway P-06CR Series
Summary of Contents for Coway P-06CR Series
- Page 1 Feed Water Feed Valve Disposed Water for Flushing Feed Valve for Feed Water Disposed Water Controlling Valve Voltage rating that matches it on the rating plate. Working Pressure 0.07-0.83MPa(10-120psi) Working Temperature 41-95℉ (5-35℃) Production Rate 700gal/day 244(W)×405(D)×450(H)mm <9.6(W)×16(D)×17.7(H)inch> 12kg(26.5lb) Without any prior notice, all or parts of the product are subject to change for the purpose of improving the performance of the product.
-
Page 2: Table Of Contents
Case of Need Service Warranty Information If you do need service, make a phone call to customer center. ※This system (P-06CR ) conforms to NSF/ANSI 58 for the reduction of Pentavalent � Arsenic, Barium, Cadmium, Mercury, Selenium, Radium 226/228, Trivalent chromium, Hexavalent chromium, Lead, Nitrate/Nitrite as verified and substantiated by test data. -
Page 3: Installation & Safe Use
● Do not use a damaged power cord or plug, and if the plug cannot be inserted securely into an outlet, please make the necessary adjustments for the purpose of avoiding fire or shock hazards. If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly qualified person in order to avoid danger. -
Page 4: Features
� Innovative Tankless R/O Technology Coway invented a tankless R/O water filtration system which is very space-efficient. � Safer Structure The risk of water leakage is diminished by using an electronic valve. -
Page 5: Names Of Each Part
NAMES OF EACH PART Front/Rear Extraction Fitting Outlet Cap Restart Button Indication Part Then, connect the faucet with the adaptor. Power Cord Inlet (Orange Color) Outlet (Blue Color) ※Check fitting and tubings are the parts that can be replaced. Installation Accessory Brief User’s Reducer Fitting Adapter... -
Page 6: How To Use
HOW TO USE WARNING Make sure that there’s no water leakage before plugging in the power cord. Preparation Before Use Step1 Wind the teflon tape on the Step2 adaptor and fit it to the pipe. Shall install the adaptor with connector on the cold water pipe. -
Page 7: How To Replace Filter
HOW TO REPLACE FILTER Step1 Filter replacement time is indicated when the corresponding LED of filter flickers in window display. Step2 Each of A, B and C respectively represents neo-sense filter, RO membrane filter and fine post- carbon filter. Step3 Close water lead-in valve and pull out plug. -
Page 8: Water Filtration System
The product water should be tested every 6 months to ensure that the contaminants are being reduced effectively. Please contact your local dealer or Coway to initiate this service. STEP1, 2 Neo-sense Filter (Sediment Filter + Pre-carbon Filter) The filter can reduces various foreign bodies that come from the feed water pipe such as: dirt, sand,rust particles, VOCs and chlorine. -
Page 9: Before Contacting Customer Service
Present this Letter of Guarantee whenever repair is needed. This Letter of Guarantee is valid only in domestic where you buy this product. Keep this Guarantee carefully as it is not re-issued. Product Name Coway Water Filtration System Guarantee Period Model P-06CR * 1 year Serial No. - Page 10 MEMO...
