PREPARING THE BACKPLATE

Thermal Pad F – 1.0 mm (120 x 16 mm)
120 mm
Thermal Pad F – 2.0 mm (120 x 16 mm)
120 mm
Thermal Pad G – 2.0 mm (120 x 24 mm)
120 mm
STEP 1
After attaching the water block, a few more thermal pads need to be
cut into smaller pieces to cover all the necessary components.
EK made sure to provide you with more than an adequate quantity of
thermal pads to complete this step.
1 mm
2 mm Replacement thermal pads:
Thermal Pad F 1.0mm – (120 x 16mm) EAN: 3830046996732
Thermal Pad F 2.0mm – (120 x 16mm) EAN: 3830046996756
Thermal Pad G 2.0mm – (120 x 24mm) EAN: 3830046996794
For this step, you will need:
2 mm
STEP 1
- 15 -
CAUTION: You must remove the protective foil from both
sides of the thermal pad before installation.
Scissors
