NICKEL ACETAL

- Dimensions: (LxHxW): 334.5 x 155 x 27mm
- D-RGB LED count: 38
- D-RGB cable length: 50cm
- D-RGB connector 3-pin 5V digital LED header
Position EAN Description
1 104465 Coldplate (Nickel)
2 103974 Acetal Stand out
3 100663 EK - Badge
4 104211 Mylar sticker
5 8202 Screw M3x12 DIN7991
6 103947 FC Terminal
7 103968 Light guide
8 104469 Acetal top plate
9 104475 Backplate (Bl.elox)
10 103942 Terminal Badge
11 104216 Disc magnet 3x3
12 8311 Screw M4x20 DIN7984
13 104106 Terminal OR - 14x1 mm
14 103987 Standoff M3.5-M2.5 x 3
15 103988 Standoff M4-M2.5 x 3mm
16 103986 Standoff M3.5-M2.5 x 11.3mm
17 104187 Screw M2.5x8 AX1
18 104188 Standoff fi 4.5/2.5
19 9024 Screw M4x10 DIN7984
20 103962 Plexi insert
21 104296 LED D-RGB Dense Strip Double - 500/130mm
22 104484 Main O-ring 162 x 2 mm
23 104902 PCB cardboard
- 7 -
Quantity
1
1
2
2
2
1
1
1
1
1
2
3
2
7
4
4
7
7
13
1
1
1
1
