OPTION 2: USING THE MSI GEFORCE RTX 3080/90

GAMING X TRIO

STEP 1

Place your graphics card on the flat surface and carefully remove the

stock cooler. Do not forget to unplug all the LED and fan connectors.

Pay attention to the following steps in order to install the EK-Quantum

Vector

Use the Phillips head screwdriver to remove the three (3) green

marked screws from the GPU bracket side.

Then remove the fifteen (15) red marked screws with Phillips head

screwdriver and carefully detach the stock backplate from the PCB.

After removing the stock backplate remove four (4) blue marked

screws on retention bracket and you can move to step 2 of the process.

For this Step, you will need:

Phillips Head Screwdriver

STEP 1

- 9 -

Trio RTX 3080/90 D-RGB water block on the graphics card.

Always remove the stock cooler slowly - it might be firmly

glued to the PCB with thermal pads.
