1.8 Default settings

CD-KP is supplied with a base configuration allowing the immediate usage without any further
configuration. Some default values are reported in the following table.
Function
Addressed unit
Baud Rate
L/R key
Cmd feature in operator menu
Retransmission
Upper operator display 1
Lower operator display 1
Upper operator display 2
Lower operator display 2
Upper operator display 3
Lower operator display 3
Command menu password
Calibration menu password
Diagnostic menu password
Setup menu password
Configuration menu password
By default, CDKP is configured to communicate with units at address 1 and baud rate 19200.
The variables displayed in operator menu are: average power (P32), average current (Arst
parameter), voltage and reference signal in percentage. All the menus are protected by
password with value 255.
1.9 Start-up
Before to supply the CD-KP check that the wiring is correct and verify the supply line voltage
value (120Vac or 240Vac). Automatically, the operator menu 1 will be displayed with power
value in upper display and reference value in lower display.
If an "E" is flashing in error/alarm display, there is a communication error, CD-
KP is not able to exchange data with thyristor unit. The user must verify:
E
- that CD-KP and thyristor unit have the same baud rate
- that the address called by CD-KP is the unit's address
- that the polarities of RS485 link are correct
- that the thyristor unit is supplied and in ON condition.
If an "A" is flashing in error/alarm display, it means that CD-KP received an
A alarm indication from the thyristor unit. The user must go in the operator
menu, scroll up to alarm sub-menu (
remove its cause (see operator menu's paragraph).
www.cdautomation.com
CD-KP for CD3000E & Multidrive
Value
1
19200
Off
Off
Off
P32
P8
Arst
P8
P31
P8
255
255
255
255
255
8
Notes
Disabled
Disabled
Disabled
Power (average on 3 phases)
Reference
Current (average on 3 phases)
Reference
Voltage
Reference
Enabled
Enabled
Enabled
Enabled
Enabled
ALAr
), identify the alarm type and
