Location Requirements

Note: The 3' Cabinet is equipped with locking casters to ease installation and
maintenance. It should be located on a flat floor for proper cabinet alignment and
door operation.

Exhaust Requirements

If you intend to connect the cabinet to the optional Exhaust Connection Kit, first
examine the location to ensure that it accommodates the cabinet's exhaust duct.
The area directly above the cabinet's exhaust port should be clear of structural
elements, water and utility lines, or other fixed obstructions. There should be
enough clearance to accommodate a 5-inch diameter duct. For further information
about the cabinet's exhaust system requirements, please refer to Appendix D:
Accessories.

Electrical Requirements

The Evidence Drying Cabinet models have the following electrical requirements:
Model #
34000-00 & -10
34040-00 & -10
34050-00 & -10
34000-01 thru -04 & -11 thru -14
34040-01 thru -04 & -11 thru -14
34050-01 thru -04 & -11 thru -14
Note: An outlet with a circuit breaker rated at 10 amps for 115 volt models (5 amps
for 230 volt models) should be located as close as possible to the right rear side of
the cabinet. Power cords supplied with the Evidence Drying cabinet are 3 meters
(10 feet) long.

Drain Requirements

If you intend to connect the optional drain kit, or if you have
Model # 34000-10 thru -14, 34040-10 thru -14, or 34050-10 thru -14 you will need
to have the Evidence Drying Cabinet within 6 feet (1.8m) of a suitable floor drain.
Note: The floor drain must be located below the level of the drain hose exiting
the cabinet for all models, even the drain pump-equipped models ending -10
thru -14. This will allow complete drainage of the system during wash down
operations. The cabinet and floor drain should be located in an area not
subject to freezing temperatures.
Product Service 1-800-522-7658
Chapter 2: Prerequisites
Table 2-1
Requirements
115 VAC, 60 Hz, 6 Amps
230 VAC, 50/60 Hz, 3 Amps
