C
h
a
p
t
e
r
5
C
h
a
p
t
e
r
5
U
s
i
n
g
t
h
e
U
s
i
n
g
t
h
e
UV Lamp Models
& 34050-00 thru -04 only)
Fan/UV Light Switch
The cabinet Fan/UV Light switch is located on the upper front of the cabinet, as
shown in Figure 5-1. Turning the switch to the "Fan" position starts the blower,
drawing air in through the cabinet. Turning the switch to the "UV On" position
will allow the UV light to turn on when the door(s) is closed and the UV Security
lock is in the "ON" position.
UV Security Lock
The UV security lock, located to the right of the Fan/UV Light switch, allows the
user to lockout the UV, preventing its operation. Before evidence is loaded into the
cabinet, it is recommended that the lock be turned to the "OFF" position, and the
key removed. This will prevent the accidental activation of the UV light while
evidence is drying. The key should be stored in a convenient, secure location,
known to all of the users to prevent its loss. Recommended locations include
hanging from the bar at the top of the liner, or in the lower storage area.
Filter System Light
The Filter System Light will illuminate if the differential pressure across the filters
becomes excessive. If lit, first inspect or replace the two prefilters. If lit with clean
prefilters, replace the HEPA filter.
NOTE: If the Filter System Light illuminates during use, finish the drying of the
evidence in the cabinet, and then correct the problem before using the cabinet
again.
Product Service 1-800-522-7658
:
:
C
a
b
i
n
e
t
C
a
b
i
n
e
t
(Model # 34000-00 thru -04, 34040-00 thru -04
19
