Page 1: Content
INan016_UK A90-303 PLEASE READ ALL INSTRUCTION IN THE OWNER'S MANUAL CAREFULLY BEFORE ASSEMBLY AND USE THE TREADMILL.AND KEEP IT FOR FUTURE REFERENCE. UESR’S MANUAL... -
Page 2: Table Of Contents
CONTENT CONTENT ------------------------------------------------------------------------------------------------------------------------------- IMPORTANT SAFETY PRECAUTIONS -----------------------------------------------------------------------------------3 ASSEMBLY INSTRUCTIONS ----------------------------------------------------------------------------------------------- ---5 GROUNDING METHODS ---------------------------------------------------------------------------------------------------------7 FUNCTION INSTRUCTION ------------------------------------------------------------------------------------------------------8 WARM-UP EXERCISES ----------------------------------------------------------------------------------------------------------14 MAINTENANCE INSTRUCTIONS ------------------------------------------------------------------------------------------- 15 BELT ADJUSTMENT ---------------------------------------------------------------------------------------------------------------16 EXPLODED DRAWING -----------------------------------------------------------------------------------------------------------17 PARTS LIST ----------------------------------------------------------------------------------------------------------------------------18 ERROR CODE AND SIGNIFICANCE --------------------------------------------------------------------------------------20... -
Page 3: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS WARNING：Before starting any exercise program, consult with your physician or health professional， especially the person who is above 35 years old people or has some health problems before. We take no responsibility for any troubles or hurts due to above reasons. Don't power on until you finish assembly the treadmill and covering the protected top of motor. - Page 4 14. When the treadmill is not being used, the power cord should be unplugged and the safety pull pin removed. Note the power cord of motorized treadmill made by special equipment, and if it is broken, please contact distributor quick- 15.
-
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS STEP1：Unscrew the knob(22)an- ti-clockwise about 4round,then follow the direction of arrow to unfold the Tighten post(02L/02R),finally,secure the Loosen knob(22)clockwise until its tightened. Loosen Tighten STEP2：Pull handlebar(03)out of the position as pic2 STEP3：Put IPAD(04)in hole of monitor(08) as pic3-4... - Page 6 STEP4：Put safety key(35)on moni- tor(08)as pic5 STEP5：Stick power cord(38)in main frame(01)follow the arrow as pic 6...
-
Page 7: Grounding Methods
GROUNDING METHODS This product must be grounded. If it should malfunction or breakdown, ground- ing provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equip- ment-grounding conductor and a grounding plug. -
Page 8: Function Instruction
FUNCTION INSTRUCTION Description The functions of this electronic watch LED display Hand pulse The nouns used in the manual are prescribed Treadmill Parameters”Speed” Exercise Parameters:”Distance”,”Time”,”Calorie” Manual motion mode:An exercise pattern with no set amount of exercise Instructions Motion parameters in various motion modes: The minimum display speed is 1 km/h The maximum display speed is 16 km/h The maximum exercise time in time mode: 99 minutes... - Page 9 Key function and operation instructions Start/stop -- function description:Start motor operation Operating instructions: 1.Press this button to start the motor when the electronic watch is in full manual operation mode 2.Press this button to start the motor when the electronic meter is set in the countdown mode 3.Press this button to start the motor when the electronic watch is in the auto- matic program setting state...
- Page 10 Run Instructions:The initial running speed is 1.0km /H, the time window starts to count backward according to the set running time, and the distance and calorie window starts to count positive from zero. Press the speed adjustment key to adjust the running speed value. When the set time reaches zero, the electronic watch starts to stop running slowly 2.Enter distance countdown mode:Under manual operation mode, press the mode key to select the range countdown mode.
- Page 11 Please keep your hands in the static state. The heartbeat display window will slowly change the display data, and it will be close to the current actual heart- beat value after 30 seconds Handlebar heartbeat function instruction:The following conditions may produce irregular heartbeat data 1.The grip is too tight during the hand grip test.
- Page 12 PREPARE: If you are around 35 years old, or have health problem, even this is your first time to do fitness exercise, please consult doctor or professional before use it. Before do exercise, please stand on the side to learn how to operate, such as start, stop and speed adjustment.
- Page 13 Please consult professional staff before do exercise. He can help recommen- dation exercise rate/intension and time according to your age and health condi- tion. When running, if you feel chest tightness or chest pain, irregular Heart- beats, short of breath, dizziness or other unwell, please stop immediately! And consult professional before you want continually to do exercise.
-
Page 14: Warm-Up Exercises
Warm-up Exercise -14-... -
Page 15: Maintenance Instructions
Maintenance Instruction WARNING：Please make sure pull out the treadmill's power plug before clean- ing or maintaining the product. CLEANSING：General cleaning or the unit will greatly prolong the treadmill's life. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails. -
Page 16: Belt Adjustment
BELT ADJUSTMENT If the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, re-start the treadmill and observe the running belt to see if it deviates. -
Page 17: Exploded Drawing
EXPLODED DRAWING 30 30 -17-... -
Page 18: Parts List
PARTS1 NAME NAME Main frame WELD Feel wheel Φ45*Φ21*Φ8.5 L&R Uplright WELD Feet cushion Φ38*17*M6*30 Handlebar WELD Washer Φ25*30*M6*10 M6 IPAD holder Washer Φ30*Φ6*10 ∮42*477*∮90* Front roller Screw M8*15 ∮15*538 ∮38*474*∮15*5 Rear roller Screw ST4.2*12 EVA sticker 260*131*2.0 Ground mat 69*42*42 Monitor up cover Hand pulse... - Page 19 PARTS2 NAME NAME Screw M6*35 Screw ST3.5*10 Screw M6*25 Anti-slip nut Screw M8*40 Flat washer ∮10.5*∮20*t2.0 Screw ST2.9*12 Down wire 1800mm， Bolt M8*12 Foam glue 20*2.0*1115 Washer L handlebar cover 75*55.5*32 ∮9*∮16*t1.5 Spring washer R handlebar cover 75*55.5*32 L&R UPLRIGHT Washer 146*88*28 ∮5.2*∮10*t1...
-
Page 20: Error Code And Significance
Error code and significance Fault Code Fault Description Fault Processing 1.The main console line is Check if the plug is fixed well or not plugged well Communication abnormal: 2.The main console line The control and computer Change the console line faulty has abnormal communication 3.Console faulty...
