Installation Instructions
Original Instructions
PanelView Plus 7 for PowerFlex 6000G B-frame and H-frame Drives
Catalog Numbers 702859-R, 702862-R
Topic
Overview
Retrofit Kit Items
Remove the HIM
Install the PanelView Plus 7 Graphic Terminal
Connect DC Power to the PanelView Plus 7 Graphic Terminal
Additional Resources
Overview
The PowerFlex® 6000G migrated to the PanelView™ Plus 7 graphic terminal (Rockwell Automation® PN 395635 / PV+7 catalog number 2711P-T7C22D9P), for new production,
spare parts, and replacement parts that are needed in the field (described in this publication). The PanelView Plus 7 graphic terminal is supplied in this retrofit kit. See
Retrofit Kit Items to know the parts list in this retrofit kit.
Rockwell Automation does not provide PanelView Plus 6 graphic terminal and Enhanced HIM (Human Interface Module) spare parts for PowerFlex 6000G H-frame and
B-frame drives.
This retrofit kit provides the necessary components to replace the existing PanelView Plus 6 graphic terminal or enhanced HIM on your PowerFlex 6000G B-frame or
H-frame drive with the PanelView Plus 7 graphic terminal.
Required Tools
• Phillips screwdriver
• 8 mm box wrench/socket for M5 metric screws
• Torque wrench, with torque range of 2.7...3.2 N•m (23...28 lb•in)
• Container to hold loose hardware
Retrofit Kit Items
See Table 1 for the items list of each retrofit kit for PowerFlex 6000G B-frame or H-frame drives.
Table 1 - Retrofit Kit Items
Item
Mounting plate for PanelView Plus 7
PanelView Plus 7 Graphic Terminal kit, V6.001
Flat washer
Lock washer
M5 nut
Documentation set:
• Installation Instructions
• Release notes for PanelView Plus 7 replacement
• Job aid
(1) The PanelView Plus 7 graphic terminal kit contains a PanelView Plus 7 graphic terminal, six mounting levers, and a 3-pin power connector.
702859-R
Qty Part Number
1 PN-701909
(1) 1 PN-701910
6 M-405
6 29308-002-01
6 29340-007-07
PN-703415
1
PN-702746
PN-702735
Page
1
1
2
3
6
7
Item
Mounting plate for PanelView Plus 7
PanelView Plus 7 Graphic Terminal kit, V5.001
Flat washer
Lock washer
M5 nut
Documentation set:
• Installation Instructions
• Release notes for PanelView Plus 7 replacement
• Job aid
702862-R
Qty Part Number
1 PN-701909
(1) 1 PN-701912
6 M-405
6 29308-002-01
6 29340-007-07
PN-703415
1
PN-702746
PN-702735
