1. INTRODUCTION This UHD Multi Format to HDBaseT Table Box is an HDMI, Mini-DP, and USB-C switch with audio embedding and HDBaseT output. The table box is designed to be placed on a table, or mounted to any typical table edge using a clamp.
4. SYSTEM REQUIREMENTS HDMI, DisplayPort, or USB Type-C source equipment such as media players, video game consoles, or set-top boxes. A compatible HDBaseT receiver with PoH (PSE) support is required. The use of Premium High Speed HDMI cables, and industry standard Cat.6, Cat.6A, or Cat.7 Ethernet cable is highly recommended.
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel Mini DP IN USB-C IN PUV-1660TTX AUDIO IN INPUT SELECT LINK FAC. HDMI IN RESET HDCP AUDIO IN Port: Connect to the stereo analogue output of a device such as a CD player or PC for embedding into the HDBaseT output.
HDMI IN Port & LED: Connect to HDMI source equipment such as a media player, game console, or set-top box. The LED will illuminate when the HDMI input has been selected. PWR LED: This LED will illuminate to indicate the unit is on and receiving power.
6.3 RS-232 Defaults Serial Port Default Settings Baud Rate 19200 Data Bits Parity Bits None Stop Bits Flow Control None Note: Access to control the table box transmitter’s settings is provided via the RS-232 port located on the connected receiver.
6.4 WebGUI Control Device Discovery Please obtain the “Device Discovery” software from your authorised dealer and save it in a directory where you can easily find it. Connect the unit and your PC/Laptop to the same active network and execute the “Device Discovery” software. Click on “Find Devices on Internet”...
Page 12
WebGUI Overview After connecting to the WebGUI’s address in a web browser, the login screen will appear. Please enter the appropriate user name and password then click “Submit” to log in. Note: The default user name and password is “admin”. On the left side of the browser you will see the following menu tabs where all primary functions of the unit are controllable via the built in WebGUI.
6.4.1 A/V Switch Tab This tab provides video/audio routing control as well as control over HDCP behavior, freerun settings, and naming of the inputs and output. To assign a new video route, please click the output button and then click on the button of the preferred input port to route.
Page 14
Freerun Mode: Enable or disable the video freerun function. When this is enabled, the selected freerun colour will be displayed on the screen if there is no live source on the selected input. Freerun Colour: Select the colour to display when freerun is active. Available choices are: Black, White, Red, Green, Blue, Magenta, Yellow, Cyan, Gray, and Colour Bar.
6.4.2 Automation Tab This tab provides control over the unit’s automatic control command broadcast behavior when the specified system Automation Events occur. Automation commands may be sent to 3rd party devices via standard CEC, or customizable RS-232. Note: Sending RS-232 commands requires the use of a compatible HDBaseT receiver with an RS-232 port.
Page 16
- Power On: Turn on the connected HDMI display device. - Power Off: Turn off the connected HDMI display device. - Active Source: Force the connected HDMI display device to switch to the HDMI input that this unit is connected to. - Power On + Active Source: Turn on the connected HDMI display device and force the connected HDMI display device to switch to the HDMI input that this unit is connected to.
6.4.3 EDID Tab This tab provides control over the EDID behavior of the unit. There are six internal EDIDs, three customer uploaded EDIDs, and one sink sourced EDID that can be assigned to a single input, or to all 3 as a group. The sink EDID and Customer EDIDs are also available for download to the connected PC.
Page 18
be transferred directly to the default download location on your PC. 3) Input EDID: This section provides controls for assigning a new EDID to one, or all inputs within the system. Appoint/All: Selecting “All” will allow the assignment of a single EDID to all inputs simultaneously.
6.4.4 Network Tab This tab provides network configuration options including changing the IP mode, viewing/setting the IP configuration, changing the admin login password, and changing the Web Login timeout. Note: This unit’s network defaults to DHCP mode. 1) IP Configuration: IP Mode may be switched between Static IP or DHCP.
6.4.5 System Tab This tab provides system configuration backup/restore options, controls to perform a factory reset or system reboot, firmware update support, as well as displaying the unit’s serial number. 1) System Configuration: Download: The current system configuration, including routing and settings, may be saved as an XML file to a PC.
6.5 Telnet Control Before attempting to use Telnet control, please ensure that both the unit and the PC are connected to the same active networks. Start your preferred Telnet/Console client, or use the built in client provided by most modern computer operating systems. After starting the client, connect by using the current IP address of the unit and port 23 (if the communication port number used by the unit has not been changed previously).
Page 22
COMMAND Description and Parameters set factory default Reset the unit to the factory defaults. set system reboot Reboot the unit. get fw ver Show the unit’s current firmware version. set uart 1 baudrate N1 Set the baud rate of the unit’s internal RS-232 port. Available values for N1: 4800 [4800 baud]...
Page 23
COMMAND Description and Parameters set uart 1 data bit N1 Set the data bits for the unit’s internal RS-232 port. Available values for N1: [5 data bits] [6 data bits] [7 data bits] [8 data bits] get uart 1 data bit Show the current number of data bits of the unit’s internal RS-232 port.
Page 24
COMMAND Description and Parameters set webgui password N1 Set the WebGUI login password. N1 = {Password} [ASCII, 16 characters max] get webgui password Show the current WebGUI login password. set webgui port N1 Set the unit’s WebGUI access port. N1 = 1~65535 [HTTP port number] get webgui port ...
Page 25
COMMAND Description and Parameters set telnet login N1 Enable or disable allowing Telnet logins. Available values for N1: [ENABLED] [DISABLED] get telnet login Show the current state of Telnet login allowance. set telnet timeout N1 Set the Telnet inactivity timeout value. Available values for N1: [No timeout] 1~120...
Page 26
COMMAND Description and Parameters set in N1 name N2 Set the name of the specified input. Available values for N1: [Mini-DP Input] [USB-C input] [HDMI input] N2 = {Name} [ASCII, 32 characters max] get in N1 name Show the current name of the specified input. Available values for N1: [Mini-DP Input] [USB-C input]...
Page 27
COMMAND Description and Parameters get in name list List the names of all inputs on the unit. set out auto mode N1 Set the auto switching behavior of the unit. Available values for N1: [Off ] [Auto Switch] get out auto mode ...
Page 28
COMMAND Description and Parameters get in N1 refresh rate Show the refresh rate of the specified input’s current video source. Available values for N1: [Mini-DP Input] [USB-C input] [HDMI input] get in N1 interlace Show the interlace state of the specified input’s current video source. Available values for N1: [Mini-DP Input] [USB-C input]...
Page 29
COMMAND Description and Parameters get out A sync status Show the current sync state of the HDBaseT output. Possible response values: [No sync] [Active sync] get in N1 deep color Show the detected bit depth of the signal on the specified input. Available values for N1: [Mini-DP Input] [USB-C input]...
Page 30
COMMAND Description and Parameters set feedback broadcast N1 Enable or disable the broadcast of console command feedback. Available values for N1: [Enable feedback] [Disable feedback] get feedback broadcast Show the current console command feedback broadcast state. set static ipaddr N1 Set the unit’s static IP address.
Page 31
COMMAND Description and Parameters set automation event N1 uart A N2 Enable or disable the specified Automation Event’s RS-232 response. Available values for N1: [Power on] [Output A source active] [Output A source lost] Available values for N2: [Event RS-232 response enabled] [Event RS-232 response disabled] get automation event N1 uart A ...
Page 32
COMMAND Description and Parameters get automation event N1 uart A command Show the RS-232 command string to be sent when the specified Automation Event is activated. Available values for N1: [Power on] [Output A source active] [Output A source lost] set automation event N1 uart A delay N2 ...
Page 33
COMMAND Description and Parameters set automation event N1 uart A wait N2 Set the length of time to wait after an Automation Event’s RS-232 response has been activated before ANY other Automation Event can be detected. Available values for N1: [Power on] [Output A source active] [Output A source lost]...
Page 34
COMMAND Description and Parameters get automation event N1 cec A Show the current state of the specified Automation Event’s CEC response. Available values for N1: [Power on] [Output A source active] [Output A source lost] set automation event N1 cec A command N2 Set the CEC command to send when the specified Automation Event is activated.
Page 35
COMMAND Description and Parameters set automation event N1 cec A delay N2 Set the delay time that the specified Automation Event must continue to be true before sending the defined CEC command. Available values for N1: [Power on] [Output A source active] [Output A source lost] N2 = 0~240 [Delay in seconds]...
Page 36
COMMAND Description and Parameters get automation event N1 cec A wait Show the wait time for the specified Automation Event’s CEC response. Available values for N1: [Power on] [Output A source active] [Output A source lost] set out A mask N1 Enable or disable the A/V mask setting on the HDBaseT output.
Page 37
COMMAND Description and Parameters set freerun A type N1 Set the freerun type to use when freerun is active on the HDBaseT output. Available values for N1: [Black] [White] [Red] [Green] [Blue] [Magenta] [Yellow] [Cyan] [Gray] [Colour Bar] get freerun A type Show the current freerun type used when freerun is active on the HDBaseT output.
Page 38
COMMAND Description and Parameters get in N1 hdcp mode Show the current HDCP behavior used by the specified input. Available values for N1: [Mini-DP Input] [USB-C input] [HDMI input] get in N1 hdcp status Show the current HDCP status of the specified input. Available values for N1: [Mini-DP Input] [USB-C input]...
Page 39
COMMAND Description and Parameters set in N1 edid N2 Set the EDID to use on the specified input. Available values for N1: [Mini-DP Input] [USB-C input] [HDMI input] Available values for N2: [FHD 2CH EDID] [FHD MCH EDID] [UHD 2CH EDID] [UHD MCH EDID] [UHD+ 2CH EDID] [UHD+ MCH EDID]...
Page 40
COMMAND Description and Parameters set edid N1 name N2 Set the name for the specified EDID. Available values for N1: [User EDID 1] [User EDID 2] [User EDID 3] N2 = {Name} [ASCII, 16 characters max] Note: Only User EDIDs may be renamed. get edid N1 name ...
Page 41
COMMAND Description and Parameters set all in edid mode N1 Select the EDID management mode to use (All or Appoint) for all inputs. Available values for N1: [All] [Appoint] get all in edid mode Show the current EDID management mode used by all inputs. set all in edid N1 ...
Page 42
COMMAND Description and Parameters get audio out A route Show the current audio source for the HDBaseT output. Note: Commands will not be executed unless followed by a carriage return. Commands are not case-sensitive.
7. CONNECTION DIAGRAM Laptop or PC Game Console Laptop or PC Mini DisplayPort USB-C Input Input Stereo Input Mini DP IN USB-C IN PUV-1660TTX AUDIO IN INPUT SELECT LINK HDMI IN FAC. RESET HDCP Network Switch Cat.5e/6/7 HDMI Cable Input...
8.5 HDBaseT Features HDBaseT Feature Set Transmitter Video & Audio Extension Supported LAN Extension Supported Send power to Receiver Unsupported Accept power from Receiver Supported (PoH) IR Extension Unsupported RS-232 Extension Unsupported USB 2.0 Extension Unsupported...
