TUCSON OTTOMAN BENCH
ASSEMBLY INSTRUCTIONS
We have designed our furniture with you , the customer in mind . Our clear , easy to follow ,
step by step instructions will guide you through the project from start to finish .
Feel confident that this will be a fun and rewarding project . The final product will be a quality
piece of furniture that will go together smoothly and give years of enjoyment .
Please do not return to the store
STOP
Broken or missing parts?
Need help with assembly?
If you have any questions just call 1-800-468-6447 or email us at
parts@convenience-concepts.com
DESIGNS4COMFORT
7104090
Advertisement
Table of Contents
Related Manuals for convenience concepts 7104090
Summary of Contents for convenience concepts 7104090
- Page 1 DESIGNS4COMFORT TUCSON OTTOMAN BENCH 7104090 ASSEMBLY INSTRUCTIONS We have designed our furniture with you , the customer in mind . Our clear , easy to follow , step by step instructions will guide you through the project from start to finish .
- Page 2 PAGE 2 OF 5 Please count and verify all parts before assembly Part List Allen screw(12pcs) Spring washer (8pcs) Ottoman Top (1pc) Flat washer (8pcs) Allen wrench(1pc) Shelf (1pc) Wood dowel(12pcs) Nut (4pcs) Side Rail (2 pcs) Plug (4pcs) Left Leg (2pcs) Right Leg (2pcs) Page 2 of 5...
- Page 3 Step 1 1.Attach Left Leg (4) to Ottoman Top (1) Assembly, using Allen screws (A) , Spring washers (B) and Flat washers ( C) as shown. 2. Connect Side rail (3) to Left leg (4) and Right Leg (5) by inserting Wood dowels (E). 3.
- Page 4 Step 3 1.Connect Right Leg (5) to Shelf (2) by inserting Wood dowel (E) and Nut (F) . 2. Fasten Right Leg (5) to Ottoman Top (1) by using Allen screws (A), Spring washers (B) and Flat washers (C) as shown . 3.Fasten Right Leg (5) to Shelf 2 by using Allen screw (A ).
- Page 5 Step 5 Turn ottoman bench over . enjoy your new ottoman bench . Page 5 of 5...
