SimpliFire SF-WM36 Service Manual

(Power Cord, Stones, Fan Box, Glass Front, Mounting Bracket, Screen & Flame Rod)
Model: SF-WM36, SF-WM58, SF-WM70, SF-WM94
Leave this manual with party responsible for use
and operation.
NOTICE! DO NOT discard this manual.
and maintenance instructions included.
NOTICE! DO NOT discard any hardware while
servicing.
It must be reused.
WARNING: If the information in these
instructions is not followed exactly it
may result in personal injury and/or prop-
erty damage.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Pliers
Phillips screwdriver
Electric drill and bits (1/4 in.)
Flat blade screwdriver
WARNING! Risk of Shock! Always unplug the
cord before moving or servicing.
SimpliFire • SF-WM36, SF-WM58, SF-WM70, SF-WM94 Service Manual • 2040-908 Rev. D • 1/19
SERVICE MANUAL
- Instructions -
Replacement Instructions
Power Input Cord Installation
Important service
1. Switch the main switch control on the right corner of
2. Unplug the power input cord from the wall receptacle.
3. Locate power input cord connection located on the
4. Remove one screw and metal strain relief bracket.
5. Unplug cord from appliance.
6. Install new cord on appliance and install metal
7. Plug cord into wall receptacle.
Figure 1 (SF-WM36) Power Input Cord and Strain Relief
Bracket on Lower Right of Appliance
Figure 2 (SF-WM58 & SF-WM70) Power Input Cord and
Strain Relief Bracket on Lower Right of Appliance
the appliance to the OFF position.
lower right corner of the appliance.
See Figure 1 (SF-WM36) and Figure 2 (SF-WM58 &
SF-WM70).
strain relief bracket with one screw. See Figure 1
(SF-WM36) and Figure 2 (SF-WM58 & SF-WM70).
