SimpliFire SF-ALLP50-BK Instructions Manual

NOTICE: Before you start, the walls and floor in the area of the installation should be clean, plumb and level. Any major
deviation should be remedied before installing the Boyd Build-Out Kit.
Kit Components
ITEM DESCRIPTION
A Front Face
B Mantel Shelf
C Right Side
D Left Side
E Right Inner Panel
F Left Inner Panel
G Inner Top
H Top Ledger
I Lower Shelf
J Lower Ledger
G
D
F
N
A
M
L
Figure 1
Boyd Build-Out Kit
BOK-MF-ALLP50, BOK-RTF-ALLP50
Model: SF-ALLP50-BK
- Instructions -
QUANTITY
1
1
1
1
1
1
1
1
1
1
B
K
H
I
E
J
C
SimpliFire • Boyd Build-Out Kit Instruction Manual • 2044-922 • 2/23
Tools and Supplies Needed
• Phillips Screwdriver (No. 3 preferred)
• Drill
• 5/32" or 4 mm Drill Bit
• 10 mm Socket or Nut Driver
• Level
• Stud Finder
ITEM
K Mantel Blocks
L Toe Kick Front
M Toe Kick Sides
N Shelf Support Blocks
O Wall Cleat
O
* BOK-MF-ALLP50, Modern
DESCRIPTION
Farmhouse, model shown.
QUANTITY
2
1
2
3
2
1
