Models: SF-SC43-BK, SF-SC55-BK, SF-SC78-BK, SF-SCT43-BK, SF-SCT55-BK
Leave this instruction with party responsible for
use and operation.
NOTICE! DO NOT discard these instructions.
service and maintenance instructions included.
NOTICE! DO NOT discard any hardware while
servicing. It may be reused.
Introduction
SimpliFire(R) ShadowGlo HD log sets are hand-painted
and offer true-to-life look and glow. Areas on some logs
are purposefully left unpainted, creating a stunningly real-
istic glow in the charred portions of the log when the LED
ember bed lights shine through.
There is no specific placement requirements for media
in the SimpliFire linear fireplaces. These placement in-
structions serve as a starting point for displaying the logs
included in this kit. If your fireplace is longer or shorter
than what is shown in this example, the pattern and general
concept can be repeated.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
WARNING! Risk of Shock! Always unplug the cord or
turn off the circuit breaker before moving or servicing.
A
B
C
Figure 1 SF-HDL-TIMBER Log Set
SimpliFire • SF-HDL-BIRCH, SF-HDL-TIMBER Log Instructions • 2043-950 Rev. B • 9/20
ShadowGlo™ HD Log Sets:
SF-HDL-TIMBER, SF-HDL-BIRCH
Instructions
Important
D
E
F
H
Tools and Supplies Needed
Before beginning and installation be sure that the following
tools - supplies are available.
Gloves
Magnetic Phillips screwdriver
Safety glasses
Ember Media (included with appliance)
SF-HDL-TIMBER Kit includes:
LOG
LOG
REFERENCE
QTY
LETTER
A
1
B
1
C
1
D
1
E
1
F
1
G
1
G
I
K
J
LOG
LOG
REFERENCE
QTY
LETTER
H
1
I
1
J
1
K
1
L
2
M
2
L
L
M
M
1
