• Important operating
a n d m a i n t e n a n c e
instructions included.
Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fireplaces.
The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using appliance.
INSTALLER: DO NOT DISCARD THIS MANUAL -
LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-BI30-EB and is the answer not in the manual?

Questions and answers

Related Manuals for SimpliFire SF-BI30-EB

Summary of Contents for SimpliFire SF-BI30-EB

  • Page 1 Congratulations! Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fireplaces. The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency. READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN THIS PRODUCT.

  • Page 2: Important Instructions

    Return appliance to authorized service facility for examination, electrical or mechanical adjustment or repair. • Do not use outdoors. SAVE THESE INSTRUCTIONS SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 3: Table Of Contents

    D. Servicing........16 E. SimpliFire Troubleshooting Guide ....17 F.

  • Page 4: Warranty

    Limited Firebox and heat exchanger, FlexBurn® System 3 years Lifetime (engine, inner cover, access cover and fireback) None 1 Year All purchased replacement parts Page 1 of 2 4021-645M 9/21 SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...
  • Page 5 EXPRESSED WARRANTY SPECIFIED ABOVE FOR THE APPLICABLE PRODUCT. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Page 2 of 2 4021-645M 9/21 SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 6: General Information

    Homeowner Reference Information information about your fireplace. Model Name: ___________________________________________ Date purchased/installed: __________________ Serial Number: __________________________________________ Location of fireplace: _____________________ Dealership purchased from: _______________________________ Dealer Phone: __________________________ Notes: _______________________________________________________________________________________ _____________________________________________________________________________________________ SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 7: Getting Started

    SHELL SIZE TRIM SIZE VIEWING AREA MODEL SF-BI30-EB 11-3/4 26-3/4 28-3/4 26-1/4 28-1/4 22-3/4 SF-BI36-EB 11-3/4 31-7/32 33-7/32 30-1/2 34-1/4 27-1/4 SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 8: Location

    WARNING! Risk of Fire! Keep electrical cords, drapery, furnishings or other combustibles at least 3 ft. (0.9 m) from the front of the electric fireplace. Figure 3.1 Minimum Vertical and Maximum Horizontal Dimensions of Combustible Mantels. SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 9: Installation

    *NOTE: If installing the appliance on a sub-floor, the appliance must be shimmed to accomodate the finishing flooring thickness. H1 will increase accordingly. ELECTRICAL SPECIFICATIONS: MODEL REMOTE SF-BI30-EB 120/208/240 1400/2100/2800 11.7/10.1/11.7 SF-BI36-EB 120/208/240 1400/2100/2800 11.7/10.1/11.7 Figure 4.1 Clearance Requirements SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 10: Appliance Preparation

    Additionally, in regions where cold air infiltration may be an issue, the inside surfaces may be sheetrocked and taped for maximum air tightness. Figure 4.2 Pre-drilled Hole Locations BRACKET LOCATION Figure 4.3 Bracket Locations SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 11: Installation Into Existing Fireplace

    Failure to do so could damage the d. Make sure that no wire is connected to the L2 product. See Figure 4.7. terminal. 5. Replace cord kit terminal block cover plate and retaining screws. SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...
  • Page 12 The switch is located behind the glass on the ceiling of the unit. Failure to do so could damage the product. Figure 4.7 Voltage Selector Switch SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 13: Finishing Fireplace Wall

    Ensure that you leave adequate room to remove and replace the decorative front. See Figure 4.8. 36 in. 30 in. SF-BI30-EB Finishing Dimension SF-BI36-EB Finishing Dimension Figure 4.8 Finishing Dimensions SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 14: Operating Instructions

    If the Flame effect is OFF, there is no Heater button function. See Figure 5.1. Flame Button By pressing the FLAME button, the unit will cycle through four flame effects. SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 15: Operating By Remote Control

    The Timer can be set from selected. If no timer beep to confirm command to .5 hour up to 9 hours in 1 hour is set, there will be desired timer setting. increments. no indicator. SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 16: Maintenance

    Do not attempt to service the unit your- ing needed must be performed by an authorized service self. representative. Do not attempt to service the unit your- self. Figure 6.1 Electrical Wiring Diagram SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 17: Simplifire Troubleshooting Guide

    Loose wiring Check wiring to ember bed LEDs. Ember bed does not light up Defective control board (PCB) Replace control board (PCB). Defective LED lights Replace ember bed LED lights. SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...
  • Page 18 (when heater is off) internal components components. If sound is coming from friction with the rotisserie bracket, apply grease to contact point. SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 19: Service Parts List

    Stand-off, Base Set of 2 STANDOFF-ELEC-B Hardware Bag HRDW-BI Includes: Mounting Brackets, Screw (ST4 x 8), Screws (ST4 x 12) Remote Receiver RECEIVER-ELECT Installation Manual 2040-980 PLUGIN-ELECT-B Plug-in Kit 6/23 SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...
  • Page 20 Stand-off, Base Set of 2 STANDOFF-ELEC-B Hardware Bag HRDW-BI Includes: Mounting Brackets, Screw (ST4 x 8), Screws (ST4 x 12) RECEIVER-ELECT Remote Receiver Installation Manual 2040-980 Plug-in Kit PLUGIN-ELECT-B 6/23 SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...

  • Page 21: Contact Information

    Printed in China - Copyright 2023 SimpliFire • SF-BI30-EB, SF-BI36-EB • 2040-980 Rev. K • 7/23...
