- Page 1 COMPANY WITH CERTIFIED QUALITY SYSTEM UNI EN ISO 9002 & EN 46002 MEDICAL APPLIANCE DIVISION Cod. 3413 Technician's Manual STEAM STERILIZERS Models STERILIX VACUUM PLUS STERILIX STAR STERILIX STAR FAST...
-
Page 2: Table Of Contents
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star Table of contents: 1. VACUUM PLUS / STAR / STAR FAST....CONTROL PANEL…………..… 3 2. KEY TO DISPLAYED MESSAGES ……………………………………………...… 4 3. TROUBLESHOOTING: SOLUTIONS AND REMEDIES………………………….6 4. OPERATION OF THE 121° - 134° CYCLES…………………………………..….9 5. - Page 3 Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star STERILIX VACUUM PLUS / STERILIX STAR / STAR FAST CONTROL PANEL 1) INFO DISPLAY for set-ups, temperature values and cycle time in minutes. 2) Button to deduct minutes with the door...
-
Page 4: Key To Displayed Messages
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 2. KEY TO DISPLAYED MESSAGES Indicates a block status. 01 - tPt Indicates that there has been a power failure during the sterilizing phase. 02 - rEt The user is asked to open the door... - Page 5 Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star ( For technicians only ): Draining solenoid valve shut. (15) 29 - ElS Machine status message. Pressure less than 0.8 bar. (1) 30 - PoF Machine status message. Pressure higher than 0.8 bar. (1) 31 - Pon Machine status message.
-
Page 6: Troubleshooting: Solutions And Remedies
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 3. TROUBLESHOOTING: SOLUTIONS AND REMEDIES Repeat the sterilizing process or contact the after-sales service center. 01- tPt Wait until the power supply returns. Check the socket and replace it if necessary. - Page 7 Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star Check and calibrate temperature probe type PT 100: NOTE: this operation must only be 08- otr carried out by After-sales Service staff. Autoclave on in a cold room: heat the room or check to make sure that the probe 09- Lot operates correctly.
-
Page 8: Operation Of The 121° - 134° Cycles
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 4. OPERATION OF THE 121° - 134° CYCLES THE INDICATED POSITIONS ARE ILLUSTRATED IN THE ENCLOSED HYDRAULIC LAYOUT AND WIRING DIAGRAM Once the program has been selected, the machine will start by means of door micro pos. - Page 9 Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star Once the draining phase has terminated, the N.O. solenoid valve pos. 14 closes for about two minutes to allow a vacuum to form in the chamber by means of the pump pos.
-
Page 10: Tests
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 5. TESTS TO CONDUCT WITH THE DOOR OPEN. THE INDICATED LEDS ARE ILLUSTRATED IN THE ENCLOSED POWER BOARD LAYOUT Leave the switch in the OFF position. Turn on the switch along with the DEDUCTION button and only release it when 888 appears. -
Page 11: Hydraulic System Up To Serial N
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 6. HYDRAULIC SYSTEM up to serial N° 99125091 (Vacuum) up to serial N°99131003(Star) C:\Documenti1\Manuali superati non in uso\MANUALE DEL TECNICO GB-R03.doc P. 11 of 19... -
Page 12: Hydraulic System From Serial N
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 7. HYDRAULIC SYSTEM from serial N° 99125092 (Vacuum) from serial N° 00131001 (Star) C:\Documenti1\Manuali superati non in uso\MANUALE DEL TECNICO GB-R03.doc P. 12 of 19... - Page 13 Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 8. HYDRAULIC SYSTEM from serial N° 00131004 (Star) C:\Documenti1\Manuali superati non in uso\MANUALE DEL TECNICO GB-R03.doc P. 13 of 19...
-
Page 14: Electrical System Up To Serilal N
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 9. ELECTRICAL SYSTEM up to serilal N° 00131003 (Starclave) 10. ELECTRICAL SYSTEM from serial N° 00131004 (Starclave) C:\Documenti1\Manuali superati non in uso\MANUALE DEL TECNICO GB-R03.doc P. 14 of 19... -
Page 15: Electrical System From Sterilix Star Fast
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 11. ELECTRICAL SYSTEM from STERILIX STAR FAST C:\Documenti1\Manuali superati non in uso\MANUALE DEL TECNICO GB-R03.doc P. 15 of 19... - Page 16 Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star C:\Documenti1\Manuali superati non in uso\MANUALE DEL TECNICO GB-R03.doc P. 16 of 19...
-
Page 17: Power Board Layout
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 12. POWER BOARD LAYOUT The components marked with an asterisk are not available in models without vacuum pump. Only in models 1999-2000 beginning from Serial N°991250092 The dotted line_ _ _ _ _ corresponds to the connection for models produced up to the year 1999 inclusive. -
Page 18: Adjustment Print-Out
Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 13. ADJUSTMENT PRINT-OUT THIS OPERATION CAN BE CARRIED OUT ON AUTOCLAVES WITH SERIAL NUMBERS FROM 99091000 ONWARDS. 1) Power the printer and connect it to the machine. 2) Turn on the green main switch. Press the DEDUCT and PUMP buttons at the same time. - Page 19 Technician’s manual – Steam sterilizers mod. Sterilix Vacuum Plus e Sterilix Star 14. FIG.1 C:\Documenti1\Manuali superati non in uso\MANUALE DEL TECNICO GB-R03.doc P. 19 of 19...
