- Page 1 User Manual Series EQC-Counting Scale User Manual Price Computing Scale Digital Counting Scale...
- Page 2 Cautions Upon receiving the scale, please take at least 8 hours to recharge the battery before you start to operate this scale. Please recharge the battery after a long period of storage (more than one month). It takes 8~10 hours to fully recharge the battery.
- Page 3 Dimensions EQC: EQC-Counting Scale User Manual...
- Page 4 Symbols on LCD Zero Indication Cursor appears on the bottom edge of WEIGHT LCD (above of printed on the display-overlay), ZERO and indicates the scale is at zero-point. NET Weight Indication Cursor appears on the bottom edge of WEIGHT ...
- Page 5 Insufficient Unit Weight Indication () : Cursor appears on the bottom edge of UNIT WEIGHT LCD (above of printed on the display-overlay), and indicates the averaging unit weight is too light. The internal resolution of this scale is 60000. If the averaging weight per unit is less than “max capacity / 60000”, cursor will flash on UNIT WEIGHT LCD.
- Page 6 Battery Symbol - When WEIGHT LCD indicates and the scale - sounds beep for four times, it means the battery is running in low-voltage status. WEIGHT LCD will indicate continuously for reminding the user to - recharge the battery.
- Page 7 OPERATION INSTRUCTIONS 0 ~ 9 : (1) Press these keys to key in the unit price. (2) Press and hold [0] key till WEIGHT LCD display shows the voltage of battery. 6.1 ~ 6.5 means the battery is running in hi-voltage status. Less than 5.5 means the battery is running in low-voltage status.
- Page 8 TARE Press this key could get the net weight. Place a package or container on the platter and press this key to deduct the tare weight, WEIGHT LCD will show 0.000 and indicate cursors on the above of ZERO ...
- Page 9 Press this key is to set the value of unit weight. We suggest the unit weight should be heavier than the division (or sensitivity) of the scale. For a counting scale 6/15kg x 2/5g, the unit weight should not be lighter than 2g.
- Page 10 <1> Press [ALARM] key to select -Lo- (showed on UNIT WEIGHT LCD); then key in 9.500 (showed on WEIGHT LCD; then press [ALARM] key again to confirm the setting. <2> Press [ALARM] key to select -HI- (showed on UNIT WEIGHT LCD); then key in 10.500 (showed on WEIGHT LCD;...
- Page 11 M1 ~ M8 : 8 direct PLU for saving the unit prices. Example: Save 7.50 into M3 memory bank Key in [7] [5] [0] >> Press and hold [M3] key till the scale sounds beep >> Finish setting. At this moment, pressing [M3] key could recall $7.50 showed on UNIT PRICE LCD.
- Page 12 RS232 Interface Connection: <optional device> For EQP / EQPL models SCALE 5 4 3 2 1 5 4 3 2 1 DATA OUT 9 8 7 6 9 8 7 6 RS232 Wiring Configuration: Baud Rate: 9600 Parity: None Stop Bit: 1 Data Bit: 8 EQC-Counting Scale User Manual...
-
Page 13: Recharge The Battery
Recharge the Battery Power off the scale and connect the power cord to an AC outlet. CHARGE LED will indicate the ongoing status of the battery. It takes about 8~10 hours to fully recharge the battery. CHARGE LED: Color of LED Status of the battery Initial Connection ORANGE... - Page 14 Digital Counting Scale We do more than you expect EQC-Counting Scale User Manual...
