Summary of Contents for Hocom GRW Series
- Page 1 User Manual Series GRW Weighing Scale User Manual Digital Weighing Scale...
- Page 2 Cautions Upon receiving the scale, please take at least 8 hours to recharge the battery before you start to operate this scale. Please recharge the battery after a long period of storage (more than one month). It takes 8~10 hours to fully recharge the battery.
- Page 3 Panel & Keypad The below panel & keypad are suitable for table scale/ Indicator/bench scale/floor scale. ※Installation Diagram of Bench Scale: please see page 10. GRW Weighing Scale User Manual...
-
Page 4: Symbols On Lcd
Symbols on LCD Zero Symbol appears on the left-bottom corner of LCD, and indicates the scale is at zero-point. Tare Weight Symbol appears on the bottom edge of LCD, and indicates the tare weight has been deducted. Battery Symbol ... - Page 5 Operation Instructions Backlight (optional) Please press and hold [MODE] key till the scale sounds beep in order to enable or disable the optional Backlight. MODE : Select the weighing mode (kg / lb / oz / ＊: This key has no funtion. ...
- Page 6 2. Hi/Lo Weight Limit: Press and hold [ALARM] key till the scale sounds beep and LCD indicates -Lo-. 1. Press [ALARM] key to enter -Lo- mode to set up -Lo- Weight Limit. 2. Use [ALARM] and [MODE] keys to set up the value of -Lo- Weight Limit.
- Page 7 Example 1: Set up 2.00 in -Lo- mode (-Lo- Weight Limit only). If the measured weight ﹤2kg The cursor will not appear and the scale will not sound beep repeatedly. If the measured weight ≧2kg The cursor will appear indicate the location on Hi. and scale will sound beep repeatedly.
- Page 8 MR Press this key to recall the data one by one which is saved in the memory bank by press [M+] key. When the last data is showed, press [MR] key again will show the total accumulation weight on LCD. MC Press this key could delete all accumulated data in the memory bank.
- Page 9 2. Press and hold [MODE] key till LCD shows S= 10, and then quickly (within 3 seconds) press [MODE] key again to select S=100 (10、20、50、100 could be selected for the sample-quantity of the measured subject). 3. Wait till LCD shows 100. The scale has finished calculating the averaging unit weight of the measured subject.
-
Page 10: Recharge The Battery
Recharge the Battery Power off the scale and connect the power cord to an AC outlet. CHARGE LED will indicate the ongoing status of the battery. It takes about 8~10 hours to fully recharge the battery. CHARGE LED: Color of LED Status of the battery Initial connection ORANGE... -
Page 11: Installation Procedure
Installation Diagram of Bench Scale List of Components: Item <1> Indicator <2> Regulator <3> Stainless Steel Tube <4> Tube Base <5> Stainless Steel Platter <6> Main Structure <7> Cable of Load Cell <8> Connector Installation Procedure: A. Screw <4> Tube Base and <6> Main Structure together (with 2 screws of Tube Base). - Page 12 Digital Weighing Scale We do more than you expect GRW Weighing Scale User Manual...
