Summary of Contents for Hocom AEPL-M Series
- Page 1 User Manual AEPL-M Series Price Computing Scale...
- Page 2 AEPL-M Series User Manual...
- Page 3 Do not keep the weight placed on the platter for a long period. Keep the scale away from the environment with high temperature, high humidity, heavy press, and heavy bump. Always make sure the scale is located in a flat and plane surface. AEPL-M Series User Manual...
- Page 4 Dimensions AEP L-M(with Pole Display): AEPL-M Series User Manual...
-
Page 5: Symbols On Lcd
Indication of kg、100g Weighing Mode () : cursor flashes on the bottom edge of UNIT PRICE LCD (above of printed on the 100g display-overlay), and indicates the present weighing mode. AEPL-M Series User Manual... - Page 6 If the battery is still running in low-voltage status without being recharged, WEIGHT LCD will indicate -OFF- and the scale will sound beep for eight times. Please power off the scale and recharge the battery right away. AEPL-M Series User Manual...
- Page 7 (1) Press this key to set the decimal point for the unit price. (2) Press and hold [] key till the scale sounds beep to enable or disable optional Backlight. Press this key to delete the setting values of unit price. AEPL-M Series User Manual...
- Page 8 [C] key to delete this figure. + : Press this key to operate the addition (for non-weighing items). Key in a unit price and then press [+] key to save the figure save it into the memory bank. AEPL-M Series User Manual...
- Page 9 ; then press [CE] key could go back to normal operating mode. (2) Key in 50, then press [X] key, then [2] key, LCDs will show: 100.00 , press [+] key to save the figure into the memory bank. AEPL-M Series User Manual...
- Page 10 Key in [7] [5] [0] >> Press and hold [M3] key till the scale sounds beep >> Finish setting. At this moment, press [M3] key could recall $7.50 showed on UNIT PRICE LCD. To modify the setting figure of M3, please just follow the above steps again. AEPL-M Series User Manual...
- Page 11 Press this key to recall the data one by one which is saved in the memory bank by pressing [M+] or [+] key. When the last data is showed, press [MR] key again will get the total accumulation unit price on TOTAL PRICE LCD. AEPL-M Series User Manual...
- Page 12 Key in [7] [5] [0] >> Press and hold [10] key till the scale sounds beep >> Finish setting. At this moment, press [10] key could recall $7.50 showed on UNIT PRICE LCD. To modify the setting figure of [10], please just follow the above steps again. AEPL-M Series User Manual...
- Page 13 RS232 Interface Connection: <optional device> SCALE 5 4 3 2 1 5 4 3 2 1 9 8 7 6 9 8 7 6 RS232 Wiring Configuration: Baud Rate: 9600 Parity: None Stop Bit: 1 Data Bit: 8 AEPL-M Series User Manual...
-
Page 14: Recharge The Battery
It takes about 8~10 hours to fully recharge the battery. CHARGE LED: Color of LED Status of the battery Initial Connection ORANGE Charging GREEN Fully-charged Power Supply AC: 230V±10%, 50Hz DC: 6V/4Ah rechargeable battery; P=0.2W(max) AEPL-M Series User Manual... - Page 15 AEPL-M Series User Manual...
- Page 16 Price Computing Scale We do more than you expect AEPL-M Series User Manual...
