- Page 1 User Manual Series TAP- User Manual Pricing Scale DIGITAL PRICING SCALE...
- Page 2 Cautions Upon receiving the scale, please take at least 8 hours to recharge the battery before you start to operate this scale. Please recharge the battery after a long period of storage (more than one month). It takes 8~10 hours to fully recharge the battery.
- Page 3 Dimensions The below panel & keyboard are suitable for table scale / indicator / bench scale. TAP- User Manual Pricing Scale...
-
Page 4: Symbols On Lcd
Symbols on LCD ZERO Indication Cursor appears on the WEIGHT LCD Display (above printed on the display-overlay), and indicates ZERO the scale is at zero-point. NET Weight Indication Cursor appears on the WEIGHT LCD Display (above ... - Page 5 Indication of kg、100g Weighing Unit Cursor will flash on the UNIT PRICE LCD Display (above of printed on the display-overlay). This kg, 100g cursor indicates the present weighing unit. Battery Symbol - - When LCD indicates and the scale sounds beep for four times , it means the battery is running in ...
- Page 6 Operation Instructions 0 ~ 9 : Press these keys to key in the unit price. (1) Press this key to set the decimal point for the unit price. (2) Press and hold [] key till the scale sounds beep to enable or disable optional Backlight.
- Page 7 TARE ZERO (1) Press this key to make the scale be at zero-point. WEIGHT LCD Display will indicate cursor on the above of (printed on the display-overlay). ZERO (2) Press this key could get the net weight. Place a package or container on the platter and press this key to deduct the tare weight, WEIGHT LCD Display will show 0.000 and indicate...
- Page 8 M+ : Press this key could save the measured weight, unit price, and total price into the memory bank ( up to 99 data accumulation). MR : Press this key to recall the data (16 one by data recall) one that is saved in the memory bank by press [M+] or [+] key.
- Page 9 RS232 Interface Connection: <optional device> 5 4 3 2 1 5 4 3 2 1 DATA OUT 9 8 7 6 9 8 7 6 RS232 Wiring Configuration: Baurate: 9600 Parity: None Stop Bit: 1 Data Bit: 8 TAP- User Manual Pricing Scale...
-
Page 10: Recharge The Battery
Recharge the Battery Power off the scale and connect the power cord to an AC outlet. CHARGE LED will indicate the ongoing status of the battery. It takes about 8~10 hours to fully recharge the battery. CHARGE LED: Color of LED Status of the battery Initial Connection ORANGE... -
Page 11: Installation Procedure
Installation Diagram of Bench Scale List of Components: Item <1> Indicator <2> Regulator <3> Stainless Steel Tube <4> Tube Base <5> Stainless Steel Platter <6> Main Structure <7> Cable of Load Cell <8> Connector Installation Procedure: A. Screw <4> Tube Base and <6> Main Structure together (with 2 screws of Tube Base). - Page 12 DIGITAL PRICING SCALE We do more than you expect TAP- User Manual Pricing Scale...
