SIGLENT SHS800X Quick Start Manual

SIGLENT SHS800X Quick Start Manual

Handheld digital oscilloscope
Hide thumbs Also See for SHS800X:
Table of Contents

Advertisement

Quick Links

Download this manual
SHS800X
SHS1000X
Handheld Digital
Oscilloscope
Quick Start
QS_EN01D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHS800X and is the answer not in the manual?

Questions and answers

Related Manuals for SIGLENT SHS800X

Summary of Contents for SIGLENT SHS800X

  • Page 1 SHS800X SHS1000X Handheld Digital Oscilloscope Quick Start QS_EN01D...

  • Page 3: Copyright Information

    Declaration SIGLENT products are protected by patent law in and outside of P.R.C. SIGLENT reserves the right to modify or change parts of or all the specifications or pricing policies at the company's sole decision. Information in this publication replaces all previously corresponding material.

  • Page 4: Table Of Contents

    SAFETY TERMS AND SYMBOLS ..................... 1 MEASUREMENT CATEGORY ......................2 QUICK START ............................ 3 INTRODUCTION OF SCOPE PANEL ....................7 INTRODUCTION OF METER PANEL ....................12 INTRODUCTION OF RECORDER PANEL ..................14 INTERFACE GLANCE ........................17 TROUBLE SHOOTING ........................18 SHS800X&SHS1000X Quick Start...

  • Page 5: General Safety Summary

    Cue and its meaning DANGER Indicates direct injury or hazards that may happen. WARNING Indicates potential injury or hazards that may happen. CAUTION Indicates potential damage to the instrument or other property that may happen. SHS800X/SHS1000X Quick Start...

  • Page 6: Measurement Category

    Used for measurements installed in buildings, such as junction boxes, circuit breakers, distribution boards and equipment that are permanently connected to fixed installations.  CAT IV: It is used for measuring at the source of low-voltage devices, such as electricity meters and primary overcurrent protection devices. SHS800X/SHS1000X Quick Start...

  • Page 7: Quick Start

    Quick Start Product Appearance SHS800X SHS1000X SHS800X/SHS1000X Quick Start...
  • Page 8 5. Connect the DC-DC adapter to the connector on the left side (top view) of the oscilloscope and charge the battery to a full state the first time power on. Figure 1 Figure 2 Figure 3 SHS800X/SHS1000X Quick Start...
  • Page 9 Measurement Connection The SHS800X and SHS1000X series handheld oscilloscope measurement accessories include oscilloscope probes, multimeter probes, current adapters. 1. Oscilloscope probe All oscilloscope probes should be properly compensated before their first use with the oscilloscope. The following steps illustrate the proper probe compensation procedure.
  • Page 10 To test current, insert a current adapter between the meter input and the meter probe. There are two different adapters, SCD600MA and SCD10A, which have built-in sampling resistors and fuses, can be used with the multimeter's mA meter and A meter respectively. SHS800X/SHS1000X Quick Start...

  • Page 11: Introduction Of Scope Panel

    Introduction of Scope Panel LCD Display Trigger Control Menu Softkey Single function Control Buttons Multifunction Control Buttons Power Button Universal Knob Multimeter Inputs Vertical Control Oscilloscope Analog Inputs Horizontal Control SHS800X/SHS1000X Quick Start...
  • Page 12 Additionally, it can also be used to modify parameters and input filenames. For more detailed usage information, please refer to the user manual. SHS800X/SHS1000X Quick Start...
  • Page 13 Navigate This button can open navigate function. It supports three navigate types: time, search event, history frame. Math This menu provides various math operation which includes adding, subtracting, multiplying, dividing, FFT, integral, differential and square root. SHS800X/SHS1000X Quick Start...
  • Page 14 Push the button can automatically set the waveform to adapt the display according to its frequency and amplitude. Default Push the button can reset the oscilloscope to the default configuration. Run / Stop This button provides the ability to enable or stop waveform acquisition. SHS800X/SHS1000X Quick Start...
  • Page 15 Indicates the current trigger coupling mode is DC coupling, Indicates the current trigger type is rising edge trigger. :Indicates CH1 open, Indicates the channel is in DC coupling mode, Indicates the voltage of each grid is 2V. Softkey function menu. SHS800X/SHS1000X Quick Start...

  • Page 16: Introduction Of Meter Panel

    Introduction of Meter Panel Meter Button Universal Knob Menu Softkey Hold Button SHS800X/SHS1000X Quick Start...
  • Page 17 The actual input value = relative value + measured value; When off, actual input value = measured value. Auto / manual selection menu. Measurement range selection menu. Measurement Logger function menu. SHS800X/SHS1000X Quick Start...

  • Page 18: Introduction Of Recorder Panel

    Introduction of Function Menus Button Description Recorder Button Press to enter Recorder mode. F1~F5 Press to active sample logger or measurement logger. Universal Knob Use the knob to quickly select the recorder interval in measurement logger and sample logger mode. SHS800X/SHS1000X Quick Start...
  • Page 19 Sampling rate and total number of samples. Indicates the file name of the saved or recalled data. Setup menu. Including sampling rate setting, data storage mode selection. Read the user manual for details. Start/Stop recorder menu. Recall data menu. SHS800X/SHS1000X Quick Start...
  • Page 20 Display area of the measurement trend chart. 790mV is the value corresponding to the vertical center of the trend label. ± 1V is the display range relative to the center position. Measurement parameters. Measurement Logger function menu, read the user manual for details. SHS800X/SHS1000X Quick Start...

  • Page 21: Interface Glance

    Interface Glance The Right Side Panel USB Device: Connects with a PC for remote control USB Host Port Probe Compensation / Ground Terminal Hand strap installation slot The Left Side Panel Hand strap installation slot Charging Interface SHS800X/SHS1000X Quick Start...

  • Page 22: Trouble Shooting

    Check if the power switch is faulted. Check whether the fuse is burned out. If the fuse needs to be changed, please contact SIGLENT as soon as possible, return the instrument to the factory, and repair it by service personnel authorized by SIGLENT.
  • Page 23 Make sure the USB disk being used is of flash type, the instrument does not support USB of hardware type. Restart the instrument and then insert the USB to check it. If it is still in abnormal use, please contact with SIGLENT. SHS800X/SHS1000X Quick Start...
  • Page 24 DC power supplies, electronic loads and other general purpose test instrumentation. Since its first oscilloscope was launched in 2005, SIGLENT has become the fastest growing manufacturer of digital oscilloscopes. We firmly believe that today SIGLENT is the best value in electronic test & measurement. Headquarters: SIGLENT Technologies Co., Ltd...
