Tamar Bathroom - 1 Drawer 2 Door Unit
Assembly Instructions -
Dimensions
Width - 40cm
Depth - 29cm
Height - 86cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
833/7146
MADE IN
BRITAIN
Issue 1 - 24/04/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tamar Bathroom 833/7146 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Tamar Bathroom 833/7146

  • Page 1 Tamar Bathroom - 1 Drawer 2 Door Unit Assembly Instructions - 833/7146 Please keep for future reference Dimensions Width - 40cm Depth - 29cm MADE IN Height - 86cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 24/04/13...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 15kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Rail (D2165A) (D2160A) (399 x 290mm) (359 x 89mm) Left End 2 Right End Base Shelf...
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the holes shown on the back of the drawer front Note: Tighten the metal dowels up fully against...
  • Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
  • Page 7 Assembly Instructions Step 7 Prepare the left end Place a runner onto the left end Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and use the 2nd hole from the back to fit the 2nd screw...
  • Page 8 Assembly Instructions Step 8 Prepare the right end Place a runner onto the right end Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and use the 2nd hole from the back to fit the 2nd screw...
  • Page 9 Assembly Instructions Step 9 Prepare the base Insert 4 large locking nuts into the base Step 10 Join the right end and base Push the base onto the right end Note: The back and front edges must be flush. Use a screwdriver to tighten the 2 large locking nuts fitted to...
  • Page 10 Assembly Instructions Step 12 Fit the 2 rails Push the 2 rails onto the right end Use a screwdriver to tighten the large locking Finished fitted to each of front edge the rails Finished front edge Step 13 Fit the left end Push the left end onto the assembly.
  • Page 11 Assembly Instructions Step 15 Note: The back Fit the top edge of the top must be flush with Lower the top onto the end panels the assembly. Note: The top must be flush with the back edge of the left and right end. Use a screwdriver to tighten the 4 large locking nuts...
  • Page 12 Assembly Instructions Step 17 Secure unit to a wall To prevent possible overbalancing we recommend that this unit is secured to a suitable wall by use of the metal bracket fitted to the of the unit. Fixings are not supplied as they will need to suit the wall type, and the Top of unit...
  • Page 13 Assembly Instructions Step 19 Fit the shelves For each of the 2 shelves , insert 4 shelf studs into the end panels Lower the 2 shelves down onto the shelf studs Step 20 Prepare the 2 doors Push fit 2 hinges into each of the doors Secure each hinge with...
  • Page 14 Assembly Instructions Step 21 IMPORTANT Drill 2 handle holes in Carefully choose which 2 holes each of the doors you need to drill in each door Important: Please follow these instructions carefully. ONLY drill these Lay the 2 doors 2 holes in 1 door down onto a smooth surface.
  • Page 15 Assembly Instructions Step 22 Fit the door and the handle Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the...
  • Page 16 C. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2874...
