Under Basin Unit
Assembly Instructions
833/2763
- please keep for future reference
Dimensions
Width - 48cm
Depth - 30cm
Height - 60 cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Issue 2 - 09/09/10
Advertisement
Related Manuals for Argos Under Basin Unit 833/2763
Summary of Contents for Argos Under Basin Unit 833/2763
- Page 1 Under Basin Unit Assembly Instructions 833/2763 - please keep for future reference Dimensions Width - 48cm Depth - 30cm Height - 60 cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Issue 2 - 09/09/10...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 1 and 2.
- Page 3 Components - Panels Please check you have all the panels listed below 1 Top x 1 2 Left side x 1 3 Right side x 1 (48(w)cm x 30(d)cm) (58.5(h)cm x 28.5(d)cm) (58.5(h)cm x 28.5(d)cm) 4 Base x 1 5 Bottom rail x 1 6 Left door x 1 (40(w)cm x 28(d)cm) (6.9(h)cm x 40(w)cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
-
Page 5: Additional Components
Additional Components Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 30mm Screw x 1 Rawl plug x 1 Safety strap x1 20mm Screw x 1 Tools required... - Page 6 Assembly Instructions Step 2 Insert 4 x female camlock into the underside of base shown. Step 3 Screw 2 x 35mm male camlock into the holes at the bottom of the left side and right side as shown. Insert 2 x female camlock into the holes at the top of the...
- Page 7 Assembly Instructions Step 5 Connect bottom rail to underside of base as shown. Step 6 Connect assembly completed in Step 5 to left side as shown. Tighten female camlocks in underside of base with a screwdriver ( Note: you should feel a click when the camlocks are secured.
- Page 8 Assembly Instructions Step 8 Connect knobs doors using 16mm screws shown. Connect catch plates to doors using 10mm screws as shown. Insert a hinge into the top and bottom of doors as shown. Note: it may be helpful to have assistance from another person with the next stage.
- Page 9 Assembly Instructions Step 9 Connect back panels using 10 x back panel screw as shown. Step 10 Insert 4 x shelf bracket inside the unit at the desired height as shown and set internal shelf in place. Assembly complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 LP 255.96.799...
-
Page 10: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings Important note: Important: when drilling into walls always check that there are no hidden wires or pipes etc. If plastic wall plugs (rawl plugs) Make sure that the screws and wall plugs being used are suitable for are supplied with your product, supporting your unit.
