Malibu Bathroom - Tall Unit
Assembly Instructions -
Dimensions
Width - 30cm
Depth - 28cm
Height - 147cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
833/7115
MADE IN
BRITAIN
Issue 2 - 07/08/13
Advertisement
Related Manuals for Argos Malibu Tall Unit 833/7115
Summary of Contents for Argos Malibu Tall Unit 833/7115
- Page 1 Malibu Bathroom - Tall Unit Assembly Instructions - 833/7115 Please keep for future reference Dimensions Width - 30cm Depth - 28cm MADE IN Height - 147cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 2 - 07/08/13...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 14.5 kgs. space to layout the parts before recommend the Please lift with care.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D2129A) (300 x 280mm) Base (D2132A) (260 x 276mm) Left End Right End Fixed Shelf (D2136A)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Choose which way If you would If you would you would like the like your door like your door door to open to open this to open this...
- Page 6 Assembly Instructions Step 3 Prepare the right end Refer to step 1 and, if required, fit 2 hinge plates onto the right , making sure that they face the same way as the diagram. Screw 5 metal dowels into the right end Insert 2 large locking nuts into the right...
- Page 7 Assembly Instructions Step 6 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf Step 7 Fit the fixed shelf Push the fixed shelf onto the right end Note: The back edges must be flush. Use a screwdriver to tighten the 2 large locking nuts fitted to...
- Page 8 Assembly Instructions Step 9 Fit the plinth Push the plinth onto the right end Use a screwdriver to tighten the large locking fitted to the plinth Step 10 Fit the left end Push the left end onto the assembly. Use a screwdriver to tighten the 5 large locking nuts fitted to...
- Page 9 Assembly Instructions Step 12 Fit the top Push the top onto the assembly. Note: The back edges must be flush. Use a screwdriver to tighten the 4 large locking nuts fitted to the left end and right Step 13 Fit the bracket and the plastic nails Fix the bracket in the...
- Page 10 Assembly Instructions Step 14 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 11 Assembly Instructions Step 16 Make sure that the plastic sleeve is fully pushed Fit the shelves onto the shelf stud. Insert 8 shelf studs into the holes in the end panels Lower the shelves down onto the shelf studs Step 17 Prepare the door Push fit 2 hinges into...
- Page 12 Assembly Instructions Step 18 IMPORTANT Carefully choose which hole you will need to drill Drill the handle hole in the door Important: Please follow these instructions carefully. Drill this hole if you ONLY drill have fitted the hinges this hole Lay the door down to the left end.
- Page 13 Assembly Instructions Step 19 Fit door and handle Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 14 Assembly Instructions Step 20 Adjust the door if needed Before adjusting the door, use a spirit level to check the top (or base) of the unit is level, front- to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any...
- Page 15 Lift with care. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR2869...
